micro beer brewing equipment,mini beer brewery equipment

Specifications

micro beer brewing equipment,mini beer brewery equipment

Product primary information

Structure:

1. Single layer structure, dual-layer with Jacket or Insulation. Three layer with double jacket.

2. High quality stainless steel 304 or 316L available.

3. Humanized structure design & easy to operate;

4. Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation;

5. PU Foam Insulation are available to keep temperature.

Configuration:

1. Quick open manhole

2. 360 degree rotation CIP spraying ball;

3. Sanitary breathing cover

4. Adjustable triangular legs

5. Dismountable materials input pipe assembly

6. Mixer: Paddle; Frame; Impeller, Be Vertical or Horizontal to choose;

(Top, bottom side & bottom, etc. places to set the mixer)

7. PU foam Insulation

8. Thermometer , Liquid level meter & ladder (According to customer requirements)

9. Other accessories can make according to customer's special requirements.

Specific

1) The tank body has interlayer and heat-insulating layer (for heating, cooling or heat insulating) The tank body, upper and lower closure heads(or taper) all adopt spinning R-angle processing. The internal wall of the tank has got mirror polishing with finish Ra≤0.4μm.

2) It has no sanitary dead corner and its wholly-enclosed design ensures that materials are always mixed and ferment at non-pollution state.

3) It is equipped with devices including air respirator, cleaning ball, sanitation inlet, viewing mirror, and viewing lamp. The fermentation process of Pharmacy, fine chemical engineering and biological products is aseptic and untainted.

4) Fermentation tank adopts aseptic system which helps avoid microorganism pollution in the air and greatly extends quality warranty period and purity of the products. We specially designed and installed aseptic respiratory air hole or aseptic normal-pressure fermentation system, which can finish circulating heat-up and cooling through medium heat-up and cooling.

The parts that contact materials are all made of stainless steel SUS304 or SUS316L. Heat preservation adopts polyurethane blister or pearl cotton. External surface adopts sand grinding surface polishing treatment. All is in accordance with GMP standard. Volume has different specifications ranging from 100-50000L.

Our company

A professional beer machine manufacturer in China with years of experience in producing and exporting.

We design fermenting tanks range from 50l home brewing used to 3000l industrial used brewery fermenting equipment,all our products can be customized and OEM.

Feel free to contact us,we welcome all friends around the world to visit our factory.
