Home > Products > Broadcast LCD Monitor > 8.4'' Small Size High Brightness Broadcast LCD Monitor
8.4'' Small Size High Brightness Broadcast LCD Monitor
- 5000 Piece / Pieces per Month
- T/T Credit Card PayPal
You May Like
Product Details
| Products Status | Stock | Application | Other | |
| Screen Size | Other, 37 inch | Response Time | 6ms | |
| Brightness | 500cd/m | Interface Type | DVI, S-Video, TV-out, Other | |
| Contrast Ratio | 1500:1 | Resolution | 1920 x 1080 | |
| Widescreen | Yes | Pixel Pitch | 0.4267x0.4267 | |
| Brand Name | user | Model Number | US-BC3701P | |
| Place of Origin | Guangdong, China |
Product Description
8.4'' Small Size High Brightness Broadcast LCD Monitor
FEATURES
Adopting the world’s most advanced system on chip (SOC-SYSTM CHIP) technology, a super single-chip solution, a-chip integrated video analog-digital conversion, comb filter, video decoder, de-interlacing, and scaling device to minimize the signal transmission in the discrete components generated image disturbance. Active and passive loop
through combined; use the US National Semiconductor’s high quality 3 SDI chip, active driver cable equalizer
output
| Specifications | ||||||||||
| Model No. | US-M0801P | |||||||||
| Panel size | 8"TFT-LCD | |||||||||
| Display area(mm)/mode | 162(W)×121.5(H) 4:3 | |||||||||
| Maximum resolution | 800x600 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.068(H)×0.203(V) | |||||||||
| Brightness (nits) | 300 nits | |||||||||
| Contrast | 300:1 | |||||||||
| Visual angle | 150°/140° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | 60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 1(BNC×1) | |||||||||
| VGA | 1 | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | DC12V 2A | |||||||||
| Maximum power consumption | 15W | |||||||||
| Standby power consumption | <1W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0℃~50℃ | |||||||||
| Storage temperature | -20℃~60℃ | |||||||||
| Working humidity | 10%~90% | |||||||||
| Storage humidity | 10%~90% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 190×160.4×45mm | |||||||||
| Panel color/appearance | White,Black,Customized | |||||||||
| Case Material | Metal case | |||||||||
| Net weight | 1.1kg | |||||||||
| Installation | Wall-mounted,Desktop(optional) | |||||||||
| Unit Price(EXW Shenzhen) | ||||||||||
| Sample Lead time | 3-7working days | |||||||||
| Bulk Order Lead time | 5-20working days | |||||||||
| Payment Terms | T/T / Western union | |||||||||
| Warranty | 1year | |||||||||
2.Functions
Detailed functions: |
Video format: MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI |
Audio format: Wave/MP3/WMA/AAC |
Image format:JPEG/BMP/TIFF/PNG/GIF |
Image resolution:480P/720P/1080P |
Play mode:Power on, single card auto loop play; classified files auto loop play; multi cards auto loop display etc |
Time:year/month/day/week/h/m/s, in the top right corner (open and close optional) |
Timing open & close:Per day 5 times, 7 days a week, free time |
Timing play:7 days a week, free set the play program everyday |
Alarm clock:Set 5 alarms one day, once ring the alarm, play the specified program |
OTG:Support copy, delete, remove, rename, build new file among different cards |
Running subtitle:Can set the play location, word size, color and back-color |
Log files:Record the play time (concise to second), the play contents |
Memory function:Power off, memory the time of the play; power on, play from the time, not from beginning |
Key and lock function:Use the remote controller before input the keyword |
Sound volume:Can set the volume of sound in the different time |
Storage card lock:Have a anti-theft lock in the case, equip 2 sets key |
Other function:Customized |
Upgrade software:Just put the upgrade file in the USB slot |
3.Advertising Kiosk Display
LCD Touch Screen Kiosk Packing
The reason why choose us?
1,We have our own ERP of the main manufacturer for digital signage and lcd video wall with over 12 years experience of producing products.
2, We could provide OEM/ODM service for all kinds of customers. Our proffesional support team will service onlin 24 hours for customers.
3, We have a very strong quality control Samples are always available for checking quality and can be dispatched to you very quickly.
4, Samples are always available for checking quality and can be dispatched to you very quickly.
6, Design ability: artwork/ Instruction manual/ product design according to customer's requirement.
7. We have our own ERP systems : Shorten lead times at low cost with responsive production planning
8. User'S Alibaba Trade Assurance Limit: US $323,000 (Still rising....)
9. Warranty (1-3 year)
Welcome your inquiry !
