Home > Products > CCTV LCD Monitor(Professional) > Security Field 32 inch CCTV LCD monitor with wide viewing angle
Security Field 32 inch CCTV LCD monitor with wide viewing angle
Negotiable
/ Piece
10 Pieces(Min.Order)
- 2000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | USER | |
| Model Number | US-M3201P |
Product Description
Specifications
32 inch CCTV LCD monitorBNC,VGA,HDMI,DVI,YPbPr,S-video
Good quality and moderate price
OEM/ODM available
CE,RoHS,FCC,UL
32 inch CCTV LCD monitor
| Specifications | ||||||||||
| Model No. | US-M3201P | |||||||||
| Panel size | 32" TFT-LCD | |||||||||
| Display area(mm)/mode | 700(W)×394(H) 16:9 | |||||||||
| Maximum resolution | 1366×768 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.51075(H)×0.51075(V) | |||||||||
| Brightness (nits) | 600cd/m2 | |||||||||
| Contrast | 4000:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | 60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 3 (BNC×3) | |||||||||
| YPbPr input | 1 (BNC×3) | |||||||||
| S-video input | 2 (BNC×2) | |||||||||
| VGA | 1 | |||||||||
| HDMI | 1 | |||||||||
| DVI | 1 | |||||||||
| Composite video output | 2 (BNC×2) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Compatible HDMI/DVI input | 480P,576P,720P,1080I,1080P | |||||||||
| 3D Comb filter | Yes | |||||||||
| Video reduction noise | Yes | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <120W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 10%~95% | |||||||||
| Storage humidity | 10%~95% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 773.6×470.0×116.2mm | |||||||||
| Panel color/appearance | White,black,customized | |||||||||
| Case Material | Metal | |||||||||
| Net weight | 23kg | |||||||||
| Installation | Wall-mounted,desktop(optional) | |||||||||
