Air Hammer C41-16KG
- 30 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | HELI | |
| Model Number | C41-16KG | Type | Air Hammer |
Product Description
Specifications
AIR HAMMER is used for forging works,such as drawing-out,upsetting,punching,chiseling,forge,welding,bending and twisting.
This pneumatic forging hammer is widely used for general Forging works,such as drawing-out,upsetting,punching,chiseling,forge,welding,bending and twisting,it is also used for forge in bolster dies.
Item | Unit | Numerical Value | |||||
Weight of falling parts | kg | 16 | 20 | 25 | 40 | 75 | |
Maximum blow energy | J | 180 | 220 | 270 | 530 | 900 | |
Distance from center of die to frame | mm | 150 | 180 | 200 | 235 | 300 | |
Distance between top and bottom die | mm | 180 | 200 | 240 | 245 | 300 | |
Number of blows per minute | min-1 | 258 | 270 | 250 | 245 | 210 | |
Dimension of top to bottom | mm | 70*30 | 90*50 | 100*50 | 120*50 | 145*65 | |
Diameter of the working cylinder | mm | 115 | 150 | 165 | 200 | 235 | |
Diameter of the compressing cylinder | mm | 125 | 155 | 170 | 205 | 240 | |
Travel distance of malleus | mm | 210 | 200 | 275 | 290 | 345 | |
Travel distance of plunger | mm | 120 | 130 | 140 | 154 | 200 | |
Forges | Round | mm |
| Φ35 | Φ45 | Φ68 | Φ85 |
Square | mm |
| 30 | 40 | 52 | 65 | |
Motor | Power | kw | 1.5 | 2.0 | 2.2 | 4.5 | 7 |
Rotate speed | rpm |
| 1440 | 1440 | 1440 | 1440 | |
Outside Size | Length | mm | 584 | 670 | 800 | 1080 | 1600 |
Width | mm | 390 | 360 | 410 | 600 | 950 | |
High | mm | 952 | 1050 | 1213 | 1389 | 1950 | |
Anvil block weight | kg |
| 190 | 247 | 400 | 850 | |
Hammer weight | kg | ~220 | ~500 | ~720 | ~1400 | ~2800 | |
