Home > Products > Desiccant air dryer controller > Dew Point Meter
Dew Point Meter
- Ningbo / Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Xinjian | |
| Model Number | XJZ-3S5 | Usage | Industrial | |
| Theory | Temperature Controller |
Product Description
Specifications
Detect and display dew point (4-20mA) of gas, output signal when dew point is abnormal.
It’s simple use, work stable, design for industrial use to detect the dew point of gas.
It’s our new product, the dry contact will be connected when dew point is up to lower limit and disconnected when dew point is up to upper limit.
The dew point signal must be a 4-20 mA current signal.
Function: | |
Set | 3 buttons |
Display | 3 pcs of 0.8’’ LED |
Detect range | 4-20mA |
Display range | -80°C ~ 20°C |
Connection | Screw |
Control | Output signal when dew point is up to lower limit and release when dew point is up to upper limit. |
Output | Relay (dry contact) |
Performance Indices: | |
Type | XJZ-3S5 |
Installation | Panel-mounted |
Install hole size | 92*92 |
Panel size | 96*96 |
Ambient temperature | -25°C ~ 55°C |
Ambient humidity | 0% ~ 99% |
back of display
