Vaisala DVT408 dew point transmitter

Specifications

It's composed of a signal converter and a dew point probe.

Model DVT408 dew point probe is manufactured by VAISALA, which output dew point signal is DC 0-5V.

Model XJZ-LD3 signal converter change the DC 0-5voltage signal to 4-20mA current signal for other instrument use.

Feature of Model DVT408 dew point probe:

1. Protection of probe: IP64 (NEMA 3S)
2. Output signal: DC 0-5V
3. Accuracy: ±4°C@ -60°C~0°C, ±3°C@ 0°C~60°C
4. Maximum pressure: 50bar (725 psi)
5. Work ambient: -5~55°C/ 0~ 99%RH
6. Material of probe is 316 stainless steel
7. Interface of probe is G1/2'' (outer screw thread)
8. Operating voltage: DC 24V
9. Analog output: DC 0-5V

Feature of Model XJZ-LD3 dew point converter

1. Rating voltage: DC24V
2. Connection: screw
3. Installation: 35mm standard rail
4. Output signal: 4-20mA
5. Input signal: DC 0-5V
