Home > Products > 75ohm coaxial cable > 19VATC coaxial cable
19VATC coaxial cable
US$ 0.1 - 1
/ Meter
5 Meters(Min. Order)
- NINGBO/SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CHAUNGYUAN/OEM | |
| Model Number | 19PATC | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
19PATC
1) Construction | ||
Center Conductor: | 1.02±0.01mm CU/CCS | |
Dielectric: | 4.7±0.1mmFoam PE | |
Shield: | Al Foil | |
Braid Coverage: | 40%-95% Al-Mg | |
Jacket: | 6.70±0.1mm PE | |
UL: | CMX, CM, CATV, CL2 | |
Jelly/APD | Per Customer’ Special Requirement | |
2) Characteristics | ||
Sparker Test: | 4000VAC | |
Impedance: | 75±3 Ohm | |
Capacitance: | 50±3pF/m | |
Velocity of Propagation: | 83% | |
Return Loss: | 20dB min (5-1000MHz) | |
Attenuation | [@68o F. (20o C.)] | |
Frequency (MHz) | Maximum (dB/100 ft.) | Maximum (dB/100 m) |
5 | 0.58 | 1.90 |
55 | 1.60 | 5.25 |
187 | 2.85 | 9.35 |
300 | 3.55 | 11.64 |
450 | 4.40 | 14.43 |
600 | 5.10 | 16.73 |
750 | 5.65 | 18.54 |
865 | 6.10 | 20.01 |
1000 | 6.55 | 21.49 |
