Home > Products > Punching Machine > J23-25T Mechnical Accentric Press Machine

J23-25T Mechnical Accentric Press Machine

FOB Price

US$ 4,985 - 4,985 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Mechanical	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	J23-25T
Voltage	220V,380V,440V 50/60Hz	Power(W)	2.2kW
Dimension(LWH)	1250x900x2030	Certification	ISO9001, CE
Warranty	12 months after delivery	After-sales Service Provided	Engineers available to service machinery overseas

J23-25T Accentric Press Machine Technical Data

Features:

Casting body,
inclinable body.
horizontally placed crankshaft is used;
rolling bearing is used instead of copper bush with lower noise and longer service life;
J23-80 and the upon models adopt balance cylinders;
Manual shut height adjustment with scale display;
High accuracy, high efficiency, simple and convenient operation, good performance, favorable price and best service.

Main Usage:

Specifications	Unit	Parameter
Nominal pressure	KN	250
Slipper stroke	mm	70
Stroke times	s.m.p	65
Max. closing height	mm	220
Adjustment of closing height	mm	60
Throat depth	mm	175
Pole distance	mm	240
Thickness of bench	mm	65
Bench size	mm	L and R: 500 F and B: 320
Size of slipper	mm	L and R: 200 F and B: 190
Size of punch shank hole	mm	Dia.: 40 Depth: 60
Dimension	mm	F and B: 1250 L and R: 900 Height: 2030
Main motor power	KW	2.2
Weight	kg	1500
