J23-160T Mechnical Accentric Press Machine

FOB Price

USD $36,340 - $36,340 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Mechanical	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	J23-160T
Voltage	220V,380V,440V 50/60Hz	Power(W)	15kW
Dimension(LWH)	2300x1700x3280	Certification	ISO9001, CE
Warranty	12 months after delivery	After-sales Service Provided	Engineers available to service machinery overseas

J23-160T Accentric Press Machine Technical Data

Features:

Casting body,
inclinable body.
horizontally placed crankshaft is used;
rolling bearing is used instead of copper bush with lower noise and longer service life;
J23-80 and the upon models adopt balance cylinders;
Manual shut height adjustment with scale display;
High accuracy, high efficiency, simple and convenient operation, good performance, favorable price and best service.

Main Usage:

Specifications		Unit	Parameter
Nominal pressure		KN	1600
Slipper stroke		mm	160
Stroke times		s.m.p	40
Max. closing height		mm	450
Adjustment of closing height		mm	120
Throat depth		mm	380
Pole distance		mm	410
Thickness of bench		mm	120
Bench size(L and R)		mm	1120
Bench size(F and B)		mm	710
Bench hole(Dia.)		mm	200
Bench hole size(L and R)		mm	530
Bench hole size(F and B)		mm	350
Size of punch shank hole(Dia.)		mm	80
Size of punch shank hole(Depth)		mm	75
Main motor power		KW	15
Dimension	F and B	mm	2300
	L and R	mm	1700
	Height	mm	3280
N.W/G.W		kg	12500/9000
Packing size		mm	3500×2000×2600
