TPX6213 Floor Type Boring Machine with CE

FOB Price

USD $171,742 - $177,664 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Place of Origin	Liaoning, China	Brand Name	DALIAN
Model Number	TPX6213	Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz
Certification	CE Certificate; ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

TPX6213 Floor Type Boring Machine Technical Data

Main Introduction:

TPX6213 floor-type boring machine can be adapted to machine casting, steel, and nonferrous word- places.
Operations include drilling, hole enlarging, boring, reaming, plane milling, spot facing, threading, and other machining processes.
The faceplate slide can be fed radically, which enables the machine to bore large size holes, turning outside diameters, and grooving.
This series of machine can be used in the industries of energy, metallurgy, mining, machinery, military, etc it is a reliable choice for machining box- type part.
Spindle is stepless speed, 4 steps speed-change by mechanical shift, 2 steps feed by mechanical shift, box ways and facing head is balanced reducing type.

In Details:

Specifications	Unit	Parameter
Spindle bore diameter		Φ130
Spindle taper		Metric 80#
Spindle speed (stepless)	r/min	4~800
Range of spindle speed	mm/min	4~200/0.05~8 250~800/0.01~2
Travel of spindle (Z - axis travel)	mm	900
Between spindle center and table surface	mm	Max.1500 Min.0
Max. spindle axial thrust	N	31360
Max, spindle torque	Nm	4900
Travel of headstock (Y - axis travel)	mm	1500
Feed range (stepless)	mm/min	4~200/0.05~8 250~800/0.01~2
Travel of front column(X - axis travel)	mm	6000
Maximum loading capacity	t/m²	15
Power of main motor	kW	15
Feed motor power	kW	5.5
Overall dimensions (LxWxH)	mm	8000x1470x4115
Weight of machine	t	38

Tel:+86 -15641121240/15641121140

Fax:+86-411-84410129

Machine color can be customized in different colors:
