Home > Products > New Products > HAIG HZ30C 3ton wheel loader
HAIG HZ30C 3ton wheel loader
USD $23,810 - $28,572
/ Set
1 Set(Min. Order)
- Shanghai or Tianjin
- T/T Credit Card
You May Like
Product Details
| Condition | New | Brand Name | HAIG | |
| Model Number | HZ30C | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 7050*2430*3120 | Rated Load | 3000KG |
Product Description
Specifications
wheel loader HZ30CDEUTZ TD226B engine /joystick/ A/C
3t wheel loader
Full hydraulic system
4 wheel drive
Adopt WEICHAI Deutz, YUCHAI or WEICHAI HUAFENG engine, powerful and reliable
Torque converter and counter-shaft trnsmission gearbox-Komatsu technology, assembled separately, higher reliability and easier maintenance
Driving Axle-Meritor technology
Fully hydraulic steering system, power shift transmission, easier operation
Bucket can be leveled automatically, optimized working device, higher productivity
Comfortable operation environment, new design cabin, Grammer seat, air-conditioner at option
Various working devices of attachment are available, such as log clamp, pipe clamp, grass fork, plow, ore bucket, loose bucket, fork etc, to meet different needs
Specifications
Rated weight | 3000Kg |
Rated capacity | 1.70m3 |
Operating weight | 9500kg |
Dump height | 3.02/3.25m |
Dump distance | 1200mm |
Wheelbase | 2760mm |
Tread | 1800mm |
Total time | 11s |
Max. breakout force | 138KN |
Max. dumping height | 5700mm |
Transportation dimensions | 7050×2430×3120mm |
Engine
Model | DEUTZ TD226B ( YUCHAI YC6B125-T10 or WEICHAI HUAFENG R6105G20 ) |
Pattern | Vertical, water-cooled, 4-stroke, direct injection |
Rated power/speed | 92kw/2200rpm |
Max. torque | 860N.m |
Normal fuel consumption | 162g/kw.h |
Total displacement | 6L |
Fuel | 0# or -10# diesel oil |
Torque converter and transmission system
Model of torque converter | YJ320B-1 |
Pattern | 3-element single stage |
Transmission type | Full-powershift, countershaft type |
Number of gear | 4 forware, 2 reverse |
Max. travel speed | 40km/h |
Axle | Xiuzhou/Laiyang |
Main reducer pattern | Arc taper gear, modelration of first grade |
Pattern of wheelside moderation | Planet gear moderation of single |
Tire
Tire size | 17.5-25 |
Steering system
Pattern | Articulated and hydraulic steering |
Min. turning radius(outside of bucket) | 5700mm |
Max. turning angle | 37°±1 |
Implement hydraulic system
Implement pump | CBGV2100 |
Displacement | 100ml/r |
System working pressure | 27.5mpa |
Distribution device model | DF25.2C |
Brake system
Brake type | Air assisted oil disc on four wheel |
Parking brake type | Soft axle control, outside bunch drum type |
