small water drilling machine100m deep for sale
- any china port
- T/T D/P D/A Credit Card PayPal
You May Like
-
2013 hot sale.KW20 multi-function mining drilling machine
-
KW10 factory price portable water well drilling rigs for sale High-wind Pressure Crawler Drill Rig kaishan brand
-
multi-function water well drill KW10 hot sale
-
multi-function water well drill KW20 hot sale
-
KW30 Portable Water Drilling Equipment
-
2012 hot sale !!depth 120-300m, diameter:168-300mm,KW30 High-Effect Hydraulic Geothermal Water Well Drilling Rigs
Product Details
| Place of Origin | Zhejiang, China | Brand Name | kaishan | |
| Model Number | KW10 | After-sales Service Provided | Overseas service center available | |
| Type | Other, Screw |
Product Description
Specifications
European design15 day delivery time
factory price
water drilling machine detailted information
100m deep KASHAN brand model:KW10
Model No | KW10 |
Dia.of hole | 115-254mm |
Drilling depth | 120m |
Working pressure | 10.5-24.6bar |
Air consumption | 16-30m3/min |
Ground clearance | 245mm |
Support cylinder stroke | 460mm |
Feed cylinder stroke | 1750mm |
Feed power | 30000N |
Lift power | 70KN |
Speed of rotator | 50-100rpm |
Rotation torque | 3200N·M |
Climb capacity | 25o |
Traveling speed | 0-2.5km/h |
Dimensions | 6000×2300×2500mm |
Weight | 6000KG |
Matched diesel Engine | |
Engine model | YC4D08 Engine |
Power | 58KW/78HP |
Rotation speed | 2400rpm |
Drilling Components | |
1.Impact Hammer | DHD360 |
2. Dia. Of rod | Φ76mm,Φ89mm |
2.Length of Rod | 3m |
3. Dia.of Bit | Φ115-254mm |
Recommend compressor | LGCY-21/20 |
Air delivery(m³/min) | 21 |
working pressure(Bar) | 20 |
diesel engine | cummins,6LTAA8.9-C325(239KW) |
Picture of water well drill machine
Matched diesel engine portable screw air compressor
LGCY-26/20 Diesel Driven portable Screw Air Compressor | ||
Air compressor | ||
Model No: | LGCY-26/20 Kaishan brand | |
Air capacity(m³/min/cfm) | 26(928) | |
Work pressure(Bar/Psig) | 20(290) | |
Fluid capacity(l) | 65 | |
Compression Stage | Double | |
Diesel Engine | ||
Engine Model No. | yuchai YC6M395L-K20 | |
Cylinder bore stroke number of cylinders | 120*145*6 | |
Capacity (L) | 9.839 | |
Rated RPM (r/min) | 1800 | |
Unload RPM(r/min) | 1400 | |
Rated Power (KW/hp) | 288(390) | |
Fuel Capacity(L) | 530 | |
Our Factory produce all kinds of air compressor and rock drill and drill rig, any feedback from you will be highly appreciate.
Ms.Susan.
Skype:air compressor1 mobile:+0086-13810843563
