Belt Conveyor Structure and Oil Resistant Material Feature Heavy Duty Conveyor Belt
- Tianjin seaport
- T/T Credit Card
You May Like
-
Belt Conveyor Structure and Heat Resistant Material Feature Conveyor Belt
-
High Quality Transport Belt Rubber Wire Rope Belt
-
800s Whole Core Fire Resistant Conveyor Belt PVC Rubber Conveying Belt for Coal Mine
-
Chemical Industries Subber Furface Whole Core Flame Retardant Conveyor Belt
-
Heat Resistant Steel Wire Conveyor Belt for Pipe Grooving Machine
-
1000mm Belt WIdth 18Mpa Ep/Polyester Conveyor Belt Manufacturer
Product Details
| Condition | New | Type | Other, flat belt conveyor | |
| Material | Other, canvas and rubber | Material Feature | Other, strong strength | |
| Structure | Belt Conveyor | Place of Origin | Hebei, China | |
| Brand Name | HUAYUN | Model Number | CC56,CC60 |
Product Description
Mould:CC56,CC60
Standard:
GB/T 7984-2001
Application:
Widely used in mining, metallurgical, architectural industry, ports, etc.
Advantages:
(1) Thin belt body;
(2) High strength;
(3) Good elasticity;
(4) high abrasion resistance.
1.Physical and mechanical properties of covering layer;
Rank of overburden performance | Tensile strength MPa. ≥ | Elongation at break%.≥ | Wear volume mm³≤ |
H | 24.0 | 450 | 120 |
D | 18.0 | 400 | 100 |
L | 15.0 | 350 | 200 |
2. Tensile property of through thickness:
a.The longitudinal tensile strength is not lower than the following nominal value:160 250 315 400 500 600 630 800N/mm.
b.The through thickness elongation rate of the belt should not less than 10%,the reference force elongation rate of trough thickness of the belt should no more than 4%.
c.Straightness:no more than 25mm.
d.Plunger bond strength:
Index name | Among the doth layer≥ | Among overburden and cloth layer | ||
|
| Thickness of overburden ≤ | Thickness of overburden > | |
Average of all samples | 3.2N/mm | 2.1N/mm | 2.7N/mm | |
