Multilayer EP Conveyor Belt With Polyester Fabric

FOB Price

US$ 23 - 50 / Meter

50 Meters(Min. Order)

Port Xingang Port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	Huayun
Model Number	EP conveyor belt, NN100, NN125,NN150, NN200, NN250, NN300, NN400 , NN500, NN600

Product Description

EP Conveyor Belt

Rubber EP conveyor belt Standards:

GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etcTypes:
Besides General Nylon Belt, there are Fire-resistant type, Cold-resistant type, Wear-resistant type,

Heat-resistant type, Acid and alkaline resistant type, Oil-resistant type, Antistatic electricity type,

High-grade type and etc.

Rubber EP conveyor belt merits:
1) high abrasion resistance, high tensile strength and good fatigue resistance;
2) Conveyor belt with nylon canvas inside has the characteristics of thin belt body, high tensile strength,

good shock resistance, good trough ability, high adhesion between plies, splendid flexibility and long

working life.

Specification and technical data of Rubber EP conveyor belt

Fabric type	Fabric structure		Fabric specs	Ply Thickness (mm/p)	strength (N/mm)					Cover thickness (mm)		Width (mm)	Length (m)
Fabric type	Wrap	Weft	Fabric specs	Ply Thickness (mm/p)	2ply	3ply	4ply	5ply	6ply	Upper	Lower	Width (mm)	Length (m)
Nylon (NN)	Nylon (N)	Nylon (N)	NN-100	0.75	200	300	400	500	600	1.5 ~ 12	0 ~ 4.5	400 ~ 2200	≤300
			NN-150	0.80	300	450	600	750	900			400 ~ 2200
			NN-200	0.90	400	600	800	1000	1200			500 ~ 2200
			NN-250	1.15	500	750	1000	1250	1500
			NN-300	1.25	--	900	1200	1500	1800
			NN-400	1.45	--	--	1600	2000	2400			800 ~ 2200
			NN-500	1.55	--	--	2000	2500	3000			800 ~ 2200

Adhesion and elongation of EP conveyor belt

Belt carcass	Adhesion strength			Elongation
	Between plies N/mm	N/mm Between rubber and carcass		Longitudinal elongation elongation at break%≥	Longitudinal elongation at reference load%≤
		Cover thickness ≤1.5mm	Cover thickness ≥1.5mm
Nylon canvas	≥4.50	≥3.20	≥3.50	10	4.0

According to the customer’s requirements, the belts could be made into endless belt,

and the covering rubber could be made into pit, chevron and level type etc.

Kinds of EP coveyor belt product process

Certification of HuaYun Brand EP conveyor belt

HuaYun brand Rubber conveyor belt have been certificated by the ISO9001/2008 and Safety

Certificate for Mining Products.

EP conveyor belt Useage

It is suitable for conveying materials at medium or long distance and under conditions of heavy

load and high speed.

EP conveyor belt Research Centre

Our company and our client

HuaYun People are adhering to the philosophy of "with integrity

and innovation to achieve development". Strive to build leading enterprise in our industry and provide the most satisfactory

products and best service for customers. With high quality and competitive prices, our products enjoy a good reputation both in

home and the abroad.
