Hiigh speed computerized chain stitch multi-needle quilting machine

Condition	New		Place of Origin	Guangdong, China
Brand Name	HengYe		Model Number	HY-W-SJ
Max Sewing Speed	300m/h		Max Sewing Thickness	80MM
Voltage	380V/50HZ 220V/60HZ		Power(W)	7KW
Dimension(L*W*H)	4720*1670*2050		Weight	5000KG
Certification	CE		Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Specifications

It is widely used for quilting high-quality mattresses , quilt covers , and household ornaments . Different patterns are availab

Specifications

It is widely used for quilting high-quality mattresses, quilt cover, and household ornaments. Different patterns are available.

   1. Optimized the mechanical structure make the higher speed and more production.

   2. The practical patented product "moving needle plate" will make the quilting patterns more elegant.

   3. More tight thread stitches make the quilting pattern have a stronger third dimension.

   4. Needle bar and press plate are controlled by a double-swinging device without cam avoiding lubrication and dirtying of material.

   5. Automatic stop motion control in case the top thread or the bottom thread breaks, automatic needle-lifting and CNC speed

adjustment.

   6. CE certificate

   7. No need to adjust the press plate's position when the thickness of quilting material varies.

   8. Outstanding features such as high rigidity, high running speed, low vibration and noise.

   9. CNC precision control system

   10. Easy preparation of CAD drawings extremely precise

   11. Strong functions of pattern-combining and multi-span quilting to enable you to quilt different patterns in each row in the mattresses of different sizes

   12. Fault detection function for ease of determining the running state of the machine at any given time
