PCB screw terminal blocks
- 1000000 Piece / Pieces per Month
- Yan Tian
You May Like
-
PCB screw terminal blocks
-
2.54mm screw type wire connectors PCB screw terminal block
-
2.54mm terminal block 125V 6A 2P-22P PCB screw type wire connectors Euro type connector
-
PCB terminal block 125V 6A 2P-22P PCB screw type wire connectors Euro type connector
-
Different types wire connectors 125V 6A 2P-22P PCB screw type wire connectors Euro type connector
-
Screw terminal block 125V 6A 2P-22P Euro type connector 2.54mm
Product Details
| Place of Origin | Guangdong, China | Brand Name | SCED | |
| Model Number | TJ952-03-A1 |
Product Description
Parameters:
UL Technical Data | B | C | D |
Rated Voltage / Current V/A | 600/30 | 600/30 | |
Wire Range AWG | 10-22 | 10-22 | |
IEC Technical Data |
| ||
Overvoltage Category | Ⅲ | Ⅲ | Ⅱ |
Contamination Class | 3 | 2 | 2 |
Rated Voltage / Current V/A | 1000 / 32 | 1000 / 32 | 1000 / 32 |
Rated Surge Voltage KV | 8 | 8 | 8 |
Rated Connecting Capacity mm2 | 4.0 | ||
Material |
| ||
Insulation Material / Inflammability Class | PA66 / UL94, V-0 | ||
Clamp Cage / Plating | Brass / Nickel Plated | ||
Terminal / Plating | Brass / Tin Plated | ||
Screw / Plating | Steel / Nickel Plated | ||
Other Data |
| ||
PCB Hole Diameter mm | φ1.6 | ||
Stripping Length mm | 7-8 | ||
Screw / Torque / lbf.in | M3 /4.4-5.3 | ||
Competitive Advantage:
1. Stable good quality
2. Competitive price
3. Quickly response
4. Full range products for selection
5. Flexible to design the exact part per customers’ demand
