BENTLY NEVADA 3500/33-01-00 – 16?Channel Relay Module for Machinery Protection Outputs
- T/T L/C PayPal D/P Western Union Other
You May Like
-
Bently Nevada 3500/25-02-01-00 Keyphasor Module – Phase and Speed Reference for Centrifugal Compressors
-
Bently Nevada 3500/60-01-00 Temperature Monitor – Reliable Multi-channel RTD Monitoring for the 3500 Protection System
-
Bently Nevada 330130-085-00-00 Extension Cable for 3300 XL Proximity Transducers
-
Bently Nevada 3500/32-01-00 Relay Module – Reliable Discrete Shutdown and Alarm Outputs for the 3500 Machinery Protection Rack
-
Bently Nevada 330130-080-00-05 – 3300 XL Proximity Extension Cable for Vibration Monitoring
-
Bently Nevada 3500/15-05-05-CN Power Supply Module – Stable Rack Power for the 3500 Machinery Protection System
Product Description
The 3500/33-01-00 is Bently Nevada’s 16?channel relay module designed to translate monitor alarms into hardwired, fail-safe relay outputs for trips, shutdowns, and annunciation. It slots into a 3500 rack and pairs with a rear I/O module, giving you flexible, plant-ready dry contacts without external relay banks. You’ll typically see it used to consolidate alarm logic and drive ESD/PLC interlocks from vibration, temperature, and speed monitors in the same rack.
You might notice it’s sometimes called an “input” module in listings; functionally, this unit is an output relay module. From my experience, that clarity matters when you’re planning wiring and trip logic across a critical machine train.
Key Features16 Form C relay outputs – Dry-contact SPDT outputs for trips, permissives, annunciators, or PLC/ESD inputs.
Configurable logic – Map any rack monitor alarms (e.g., 3500/42, /45, /60) with options for latching/non?latching, time delays, and voting (such as 2oo3).
Fail-safe behavior – Normally?energized or de?energized configurations help meet plant safety philosophies.
Integrated with the rack – Powered via the 3500 backplane; configuration and events handled through the 3500/22M TDI and configuration software.
Front-panel status – Typical OK/BYPASS indicators aid quick diagnostics during commissioning and routine checks.
One-slot footprint – Uses a single rack position with a matching rear I/O module for straightforward field wiring.
Channel grouping – Assign individual or grouped relays to alarms/trips for flexible shutdown strategies.
| Brand / Model | BENTLY NEVADA 3500/33-01-00 (16-Channel Relay Module) |
| Function | Dry-contact relay outputs for machinery protection alarms/trips |
| Power Requirements | Supplied via 3500 rack backplane (no external PSU) |
| Signal I/O Types | 16 × SPDT (Form C) dry-contact relay outputs |
| Communication / Configuration | Via 3500/22M TDI and 3500 Configuration software |
| Rack Position | Occupies one front slot with corresponding rear I/O module |
| Operating Temperature | Typically 0 to +65 °C (rack dependent) |
| Installation Method | Front module + rear I/O terminals; mounted within the 3500 rack |
This module is widely used wherever you need deterministic relay outputs tied to high?integrity monitoring:
Oil & gas and petrochemical units – compressor trains, charge pumps, steam turbines, and expanders.
Power generation – gas and steam turbines, generator auxiliaries, balance-of-plant equipment.
Refining and pipelines – booster pumps, product pumps, and custody transfer support systems.
Heavy industry – paper machines, large fans/blowers, critical gearboxes, and mill drives.
A maintenance lead at a Gulf Coast refinery told me they mapped three independent high?vibration alarms into 2oo3 voting on the 3500/33 to cut nuisance trips by half, while keeping shutdown integrity intact. That seems to be a common pattern for multi?bearing machines.
Reliability – Industrial?grade relay design and fail?safe options align with plant trip philosophies.
Compatibility – Works natively with all 3500 rack monitors; no external logic box needed in most cases.
Cost & wiring efficiency – Reduces separate relay panels and simplifies terminations to DCS/PLC/ESD.
Serviceability – Clear status indication, modular replacement, and configuration via familiar 3500 tools.
Long lifecycle support – Stable platform with a large installed base and proven spares strategy.
Cabinet/Rack – Mount in a standard 3500 rack within a well?ventilated enclosure. Keep ambient within the rack’s specified range and avoid direct heat sources.
Wiring – Use the rear I/O terminals; segregate trip circuits from low?level signals. Clearly label common, NO, and NC contacts. Observe site standards for ESD/PLC input wiring.
Grounding – Follow rack grounding practices to minimize interference and ensure safe fault clearing.
Configuration – Set latching, time delays, and voting in the 3500 configuration software. Verify each relay with a functional test before placing the machine on risk.
Routine checks – Periodically proof?test relays, confirm contact operation, and review event logs. Firmware and configuration should be managed via the 3500/22M TDI under MOC procedures.
Conformity: CE and UL/cUL for the 3500 system; hazardous area approvals (e.g., ATEX/IECEx) available by specific option codes.
Manufacturing: Built under ISO 9001 quality systems.
Environmental: RoHS alignment on many variants; confirm per part number and site requirement.
Warranty: Manufacturer’s standard warranty (commonly 1 year); extended coverage often available.
If you’re replacing legacy trip relays or standardizing across multiple racks, the 3500/33-01-00 typically gives a neat balance of channel density and configuration flexibility without complicating the shutdown architecture.
