Bently Nevada 05-IS Frame (3500/05 IS System Rack) – Intrinsically Safe Chassis for 3500 Machinery Protection

The Bently Nevada 05-IS Frame is the 3500/05 system rack variant designed for intrinsically safe field circuits. It serves as the backbone for 3500 monitoring modules, combining hazardous-area sensor connectivity with the reliability expected in critical turbomachinery and balance-of-plant protection.    From my experience, it’s typically chosen when you need proven API 670–class protection in plants that operate in Zone 1/Div 1 environments but want to keep the rack in a safe or Zone 2 cabinet.

• Intrinsic Safety (IS) backplane option – Integrates IS barriers on the rack side so proximity probes, accelerometers, and other transducers in hazardous areas can be wired directly, reducing external barrier hardware.

• 14?slot 3500 architecture – Accepts the full range of 3500 modules (e.g., 3500/40M, 3500/42M, 3500/60, 3500/25), enabling flexible machine train coverage within one chassis.

• Redundant power and communications ready – Supports dual 3500/15 power supplies and TMR-ready backplane design; in many cases, facilities run redundant power for higher availability.

• System 1 connectivity via 3500/22M TDI – Ethernet data access for condition monitoring, plus common protocols (such as Modbus/TCP) for DCS/PLC integration through the TDI module.

• Cabinet-friendly form factor – Standard 19-inch EIA rack mounting or panel mount; seems to be the easiest way to standardize across existing MCC or analyzer cabinet layouts.

• Field-proven reliability – The 3500 platform is widely used in refineries, gas processing, and power generation where continuous operation and quick diagnostics matter.

Plants that operate in flammable atmospheres typically select the 05-IS when they want to keep the rack centralized, reduce external barrier count, and maintain robust protection. Common deployments include:

• Oil & Gas: compressors, gas turbines, pumps in Zone 1 compressor halls or gathering stations.

• Refining & Petrochemical: critical pumps, fans, and expanders with API 670 compliance expectations.

• Power Generation: gas turbine trains, auxiliaries, and boiler feedwater pumps with hazardous area sensors.

• Chemicals & Fertilizers: ammonia/urea units, polymer lines, and solvent handling areas where IS field wiring is preferred.

A maintenance lead at a gas compression site mentioned they picked the 05-IS because it “cleaned up the cabinet,” removing third-party barriers and simplifying their loop drawings.

• Lower panel complexity – Internalized barriers can reduce separate barrier rail hardware and wiring, which usually cuts panel depth and assembly time.

• Lifecycle consistency – Same 3500 modules, same diagnostics, same spares strategy—just with IS capability at the rack level.

• High availability design – Redundant power and TMR-capable architecture minimize single points of failure in critical services.

• Open integration path – Through the 3500/22M TDI, data goes to historians, DCS/PLC, and System 1 without complicated protocol bridges.

• Support & documentation – In most cases, documentation is mature and field-proven, which speeds FAT/SAT and operator training.

• Cabinet & environment – Install in a ventilated, dust-free enclosure meeting local code; 19-inch EIA rack or panel cutout as applicable. Keep ambient within the recommended temperature range.

• Grounding & shielding – Bond rack and shields per Bently Nevada guidance; good grounding typically improves noise immunity and data quality.

• Hazardous area wiring – Route IS field wiring per the certified drawings. Maintain separation from non-IS circuits and follow terminal labeling on the IS backplane.

• Redundancy checks – If using dual power supplies, verify switchover and alarm behavior during commissioning; many teams schedule a semiannual power fail simulation.

• Routine care – Periodic terminal re-torque, connector inspection, and cleaning with non-residue agents. Keep firmware for TDI and modules updated under change control.

• Calibration & proof tests – Perform sensor loop checks and alarm/protection function tests at planned intervals aligned with plant standards.

You might notice the 05-IS pairs best with standard 3500 modules; the rack simply ensures the IS path is handled on the backplane.

• 3500/15 Power Supply (AC or DC variants; single or redundant)

• 3500/22M Transient Data Interface (System 1 / Ethernet, gateway functions)

• 3500/40M & 3500/42M Vibration Monitors (prox/accel)

• 3500/25 Keyphasor Module (speed and phase reference)

• 3500/60 Temperature Monitor (RTD/TC)

• 3500/32M or 3500/33 Relay/Communication options as required by the project

• CE marking and UL/cUL for the 3500 platform

• ATEX/IECEx certifications for IS-enabled configurations and applicable modules

• RoHS compliance in many regions

• Manufacturer’s warranty: typically 2 years on new parts; extended service options may be available

If your site is standardizing on 3500 and you need IS field circuits without cluttering your cabinet with third-party barriers, the Bently Nevada 05-IS Frame is, in many cases, the cleanest path—keeping the system familiar for technicians and straightforward for integration teams.
