Home > Products > TRICONEX > TRICONEX 4107 Network Interface Module

TRICONEX 4107 Network Interface Module

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T PayPal Western Union

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other	Certification	Other
Function	Other	Condition	Other
Task	Other	Mathematical Model	Other
Signal	Other	Customized	Other
Structure	Other

Product Description

TRICONEX 4107 Network Interface Module

The TRICONEX 4107 network interface module is a key component in the Triconex safety control system for enabling device networking and data exchange. Its core functional features are designed based on the DeviceNet protocol, combining high reliability, flexibility, and security. The detailed description is as follows:

I. Multi-Protocol Communication Capability

DeviceNet Protocol Support
It accesses the DeviceNet network as a slave node, complies with the IEC 62026-3 standard, and supports the master-slave communication mode.
Supports multiple message types:

I/O slave messages (Group 2 only): Realize periodic data exchange.
Poll command: The master actively queries data from the slave.
Bit_strobe command: Quickly modify the state of a single output bit.
Cyclic command: Automatically transmit data at a fixed period.
Change of State (COS) command: Trigger transmission only when data changes to reduce network load.

Automatic Baud Rate Detection
Supports three baud rates: 125/250/500 Kbps, and can automatically identify the network rate without manual configuration.

II. Flexible I/O Configuration

Built-in I/O Channels

Digital inputs: 16 channels, supporting positive logic (high-level active) or negative logic (low-level active) configuration, and can access dry contact or wet contact signals.
Digital outputs: 16-channel isolated relay outputs with a contact capacity of 2A/30V DC or 2A/250V AC, which can directly drive actuators such as solenoid valves and contactors.

Extended I/O Capability
External I/O modules can be expanded through the DeviceNet network, supporting all types of I/O in the RSTi series to achieve large-scale distributed I/O control.

III. Redundancy and Fault-Tolerant Design

Power Redundancy
Supports dual 24V DC redundant power inputs, and automatically switches when a single power supply fails to ensure uninterrupted power supply.
Communication Redundancy
Optional redundant communication interfaces (requires matching redundant network topology) to improve network reliability.
Fault Self-Diagnosis
A built-in watchdog timer monitors the module's operating status and triggers safety responses in case of abnormalities.
Communication error counting and alarming provide real-time feedback on network health.

IV. High-Security Design

SIL 3 Safety Certification
Certified to IEC 61508 SIL 3, suitable for application scenarios with the highest safety integrity level.
The Probability of Failure on Demand (PFH) is as low as 10??/h, meeting strict safety requirements.
Isolation and Protection
Electrical isolation between channels (500V AC) and between the field side and the system side (2500V AC) to prevent interference and fault propagation.
Complies with the IEC 61000-4 electromagnetic compatibility standard, with strong anti-interference capability.

V. Real-Time Data Processing

Large-Capacity Data Transmission

Input data buffer: 36 bytes (including 4 bytes for the basic module + 32 bytes for the extended module).
Output data buffer: 34 bytes (including 4 bytes for the basic module + 30 bytes for the extended module).
Supports high-speed data exchange to meet real-time control requirements.

Change of State (COS) Trigger
Updates are sent only when critical data changes, reducing network traffic and improving communication efficiency.

VI. Convenient Configuration and Maintenance

Visual Status Indication
Front-panel LED indicators display power, communication status, and fault information, supporting local diagnosis.
Remote Configuration
Communication parameters, I/O mapping, and alarm thresholds can be remotely configured through Triconex programming software (such as TriStation).
Hot-Swappable Capability
Supports online module replacement without shutdown, reducing maintenance costs.

VII. Typical Application Scenarios

Industrial Automation
Connect sensors, actuators, and the Triconex safety system to realize remote monitoring and control of equipment.
Process Safety
In industries such as petrochemicals and electric power, it serves as the communication hub for Emergency Shutdown Systems (ESD) or Fire and Gas Detection Systems (FGS).
Distributed Control System Integration
Seamlessly accesses DCS systems such as Foxboro and Honeywell to achieve cross-system data exchange.

Summary of Key Technical Parameters (based on the DeviceNet protocol):

I. Communication Parameters

Parameter	Details
Supported Protocols	DeviceNet (IEC 62026-3)
Baud Rate	Automatically detected/configured, supporting 125 Kbps, 250 Kbps, 500 Kbps
Network Topology	Supports bus or daisy-chain topology, maximum 64 nodes
Communication Distance	- 125 Kbps: up to 500 meters - 250 Kbps: up to 250 meters - 500 Kbps: up to 100 meters
Data Transmission	- Input: 36 bytes (4 bytes for basic module + 32 bytes for extended module) - Output: 34 bytes (4 bytes for basic module + 30 bytes for extended module)
Message Types	Supports I/O slave messages (Group 2 only), Poll, Bit_strobe, Cyclic, and COS commands

II. I/O Characteristics

Parameter	Details
Digital Inputs	- 16 channels (optional positive or negative logic) - Input type: dry contact or wet contact (24V DC) - Response time: ≤1ms
Digital Outputs	- 16-channel isolated relay outputs - Contact capacity: 2A/30V DC or 2A/250V AC - Service life: ≥1 million operations
Isolation Characteristics	- Isolation voltage between channels: 500V AC - Isolation between field side and system side: 2500V AC

III. Power and Power Consumption

Parameter	Details
Operating Voltage	24V DC (with a fluctuation range of -15%/+20%)
Power Consumption	≤15W (typical value)
Redundancy Support	Supports dual redundant power inputs to ensure fault tolerance

IV. Mechanical and Environmental Parameters

Parameter	Details
Dimensions	Standard Triconex module size (refer to the product manual for details)
Weight	≤1.5 kg
Operating Temperature	-40°C to +70°C (industrial grade)
Storage Temperature	-40°C to +85°C
Humidity	5% to 95% relative humidity (non-condensing)
Protection Rating	IP20 (must be installed in a control cabinet)
Installation Method	Standard DIN rail or rack mounting

V. Safety and Certification

Parameter	Details
Safety Certifications	- SIL 3 (IEC 61508) - TüV certification - CE, UL, CSA, etc.
Anti-Interference Capability	Complies with the IEC 61000-4 standard (electromagnetic compatibility)
Fault Diagnosis	- Module status indicators (power, communication, fault) - Built-in watchdog timer - Communication error counting and alarming
