TRICONEX 3701 Power Module

TRICONEX 3701 is an important power supply module in the Triconex safety control system. It is specially designed to provide stable and reliable DC power for I/O modules (such as digital input/output modules, analog modules, etc.) in the system. It serves as the "power core" ensuring the normal operation of the I/O layer of the entire control system. It is compatible with the Triple Modular Redundancy (TMR) architecture and is widely used in safety instrumented systems (SIS) or key process control scenarios with strict requirements on power supply reliability in industries such as petrochemical, electric power, and rail transit.

• Convert externally input AC or DC power (such as 220V AC, 24V DC, etc.) into standard DC voltage required by I/O modules (usually 5V DC or 24V DC, depending on the model);

• Equipped with power voltage stabilization and filtering functions to reduce the impact of external power grid fluctuations (such as voltage surges, sags, noise interference) on I/O modules, ensuring stable operation of module circuits;

• Compatible with the TMR architecture, providing reliability of power output through redundant design to avoid power loss of I/O modules due to single-point power supply failure;

• Built-in status monitoring and fault alarm functions to real-time monitor parameters such as output voltage, current, and module temperature. In case of abnormalities, fault information is fed back through indicator lights or system communication for quick troubleshooting.

•


• Triple independent power channels: The module contains three completely isolated power conversion and output channels (A, B, C) inside. Each channel has independent rectification, filtering, and voltage stabilization circuits to avoid overall power supply interruption caused by a single channel failure.

• Parallel redundant output: The three channels simultaneously output the same voltage to the redundant power interface of the I/O module, forming a "parallel power supply" mode. Even if one channel fails, the remaining two channels can still maintain normal power supply, ensuring that the I/O module is not affected.

• Load balancing and fault tolerance: The three channels achieve average distribution of load current through the design of balanced output impedance to avoid overload of a single channel; if a channel has overcurrent, short circuit, or voltage abnormality, the system can automatically isolate the faulty channel, and the remaining channels will bear the full load to ensure stable output voltage.

•


• Ensuring reliable operation of I/O modules: Through stable voltage output and anti-interference design, ensuring that the signal acquisition, processing, and output functions of I/O modules are not affected by power fluctuations;

• Improving system fault tolerance: The triple redundant channel design enables the power output to have "fault self-isolation" capability. Even if the module has partial faults, it can still maintain power supply to the I/O layer, avoiding system shutdown due to power supply problems;

• Adapting to high safety demand scenarios: In scenarios such as emergency shutdown systems (ESD) in petrochemical industry and unit protection systems in electric power industry, the redundant design and reliability of the 3701 module can meet the safety level requirements of SIL 3 and above, providing basic guarantee for the safe operation of the system.
