ABB CI862K01 3BUA000037R1 Communication Interface

I. Overview
ABB CI862K01 3BUA000037R1 is a key communication interface module. In ABB's AC 800M control system architecture, it is responsible for integrating TRIO/Genius I/O into the local AC 800M I/O. The module is connected to the CEX-Bus through the backplane, laying a foundation for stable operation. Its unique feature is that it supports direct connection to a TRIO LAN and provides a dedicated port for handheld displays, greatly facilitating on-site debugging and equipment status monitoring. With this module, a single CI862 can connect up to 30 blocks to a single LAN, and the AC 800M system can be configured with up to four single LANs or four redundant LANs. In TRIO mode, the maximum number of I/O points of the AC 800M can reach 1000, fully meeting the diverse needs of industrial automation projects of different scales for the number of I/O points and network architecture. In addition, the CI862 module also has a redundancy setting function, which can effectively improve the reliability and stability of the system operation and reduce the risk of system interruption caused by module failure. As a communication interface for TRIO blocks (remote I/O), it efficiently manages the channel data of the AC 800M controller and is a core component to ensure smooth data interaction and precise control of the system.

II. Technical Parameters

• Line redundancy: Does not support line redundancy, which means that when a communication line fails, it cannot automatically switch to a backup line to maintain communication. However, in some industrial scenarios where line reliability has been guaranteed through other means or the requirement for line redundancy is not high, this feature does not affect its normal operation.

• Module redundancy: Supports module redundancy. If a single CI862 module fails, the redundant module can quickly take over the work, ensuring uninterrupted system communication functions, effectively improving the fault tolerance and operational stability of the system, and is suitable for key industrial automation control scenarios with high requirements for system reliability.
  Hot-swap function: Supports hot swapping, allowing maintenance personnel to directly replace the faulty CI862K01 module while the system is continuously running without shutting down. This feature greatly improves the convenience and efficiency of system maintenance, effectively reduces the production interruption time caused by module maintenance, and reduces enterprise production losses.
  CEX bus connection capability: Up to 4 modules of this type can be connected to the CEX bus. Users can flexibly configure multiple CI862 modules according to the actual project scale and system complexity to build a large and complex industrial automation communication network and enhance the overall performance of the system.
  Connector type: Various connectors such as phoenix (4-pin), db9 male, db9 female are selected. These connectors have excellent electrical connection performance and outstanding mechanical stability, which can ensure the stable and reliable connection of communication lines, effectively reduce signal interference and transmission loss, and guarantee data transmission quality.
  Power consumption: At a working voltage of 24V, the typical current consumption is 190mA, and the energy consumption is at a low level. While meeting the needs of powerful communication functions, it will not bring too much burden to the system power supply, helping to reduce the overall energy consumption of the system and achieve energy-saving operation.
  Environmental parameters:

• Operating temperature: Suitable for working in the temperature range of +5℃ to +55℃ (+41°F to +131°F). Within this temperature range, the module can maintain stable performance, adapt to temperature changes in most conventional industrial environments, and ensure the continuous and stable operation of the equipment.

• Storage temperature: The storage temperature range is -40℃ to +70℃ (-40°F to +158°F). The wide storage temperature range enables it to be properly stored for backup in different environments, facilitating enterprises to flexibly arrange equipment reserves according to actual needs.

• Relative humidity: Can work normally in an environment with a relative humidity of 5% to 95% without condensation. It has strong adaptability to humidity environments, is suitable for various industrial production environments, and reduces the risk of equipment failure caused by humidity problems.
  Dimensions and weight:

• Width: 59mm (2.3 inches). The compact width design enables it to better adapt to compact installation environments when the system installation space is limited, saving control cabinet space.

• Height: 185mm (7.3 inches). The overall height conforms to the module layout specifications of the AC 800M system, ensuring coordination and adaptation with other modules during system integration.

• Depth: 127.5mm (5.0 inches). The reasonable depth setting can ensure that the module will not interfere with the normal operation of other equipment after installation, and ensure a compact and reasonable internal layout of the system.

• Weight (including base): 700g (1.5 pounds). The moderate weight is convenient for installation and maintenance personnel to operate, reducing the difficulty of manual operation both in the initial equipment installation and later maintenance and replacement.

III. Functional Features
I/O system integration: The core function is to realize the seamless integration of TRIO/Genius I/O and AC 800M system, integrating I/O devices of different architectures under the same control system. This function enables enterprises to make full use of existing TRIO/Genius I/O equipment resources during the upgrading or transformation of automation systems, avoid repeated investment, and at the same time integrate them into the advanced AC 800M control system, significantly improving equipment performance and system functions, and realizing the maximum utilization of equipment resources.
Advantages of hot swapping: Supports hot swapping function. When the system is running continuously, maintenance personnel can quickly replace faulty modules, effectively avoiding production stagnation caused by module failure shutdown. This not only greatly improves the continuity and stability of the production system but also significantly reduces maintenance costs and time costs, providing strong guarantee for efficient production of enterprises.
I/O configuration and scanning management: The CI862 unit can efficiently handle I/O configuration and I/O scanning of up to 30 TRIO blocks. Through precise I/O configuration, the working parameters and communication rules of each I/O device can be flexibly set according to actual production needs; the real-time I/O scanning function ensures that the system can timely obtain the operating status information of on-site equipment and quickly transmit control commands to executive equipment, ensuring the timeliness and accuracy of data collection and command issuance of the entire control system, and realizing precise control of industrial production processes.
Redundancy guarantee: Equipped with module redundancy function. By configuring redundant modules, when the main module fails, the standby module can automatically start working immediately and switch seamlessly, ensuring that system communication and related control functions are not affected. This redundancy design significantly improves the reliability and fault tolerance of the system, especially suitable for industrial automation scenarios with high requirements for system stability, such as chemical production and power supply, effectively reducing the risk of production accidents caused by module failure.
