ABB PPD113B01-20-111000 Controller

Technical Parameters

• Input Voltage: The applicable range is 200-250VAC, with a frequency between 47-63Hz. It can well adapt to common industrial power supply environments and effectively ensure the stable operation of equipment.

• Rated Power: Reaches 150kW, which can fully meet industrial application scenarios with large power demand.

• Rated Voltage: Provides a stable 150VDC DC voltage output to meet the power requirements of related equipment.

• Rated Current: Has a strong current-carrying capacity of 1000A, which is sufficient to support the normal operation of large-scale equipment.

• Operating Temperature Range: The normal operating temperature range is generally between -40℃ and +70℃. In some cases, it can also work stably in the environment of -20℃ to +60℃. Whether it is a high-temperature smelting workshop or a cold outdoor operation site, it can maintain normal operation.

• Data Bus: Adopts an advanced 32-bit data bus with a data bandwidth of up to 100Mbps, effectively ensuring fast data transmission and processing, and meeting the real-time requirements in industrial production.

• Transmission Rate: Maintained at 10Mbit/s to ensure stable and efficient data communication.

• Memory Access: 8MB memory access address field and 8MB I/O access address field are reserved to facilitate data storage and calling, and provide sufficient space for system operation and data processing.

• Interface Type: The front panel is equipped with a 15-pin SUB-D socket with a slide lock for the AUI interface, which can be conveniently connected to commercial transceivers with AUI connectors (15-pin female plug DIN 41652) to achieve effective communication with external equipment.

• Protection Level: The protection level reaches IP20, which can effectively block the intrusion of large particles of dust, provide a certain degree of protection for internal precision circuits, and is suitable for installation environments in general industrial control cabinets.

• High-precision Data Processing: Has excellent analog input accuracy, can accurately collect various signals, provide accurate measurement data for the control system, and ensure that industrial process control meets high-precision standards. For example, in the chemical production process, it can accurately monitor key parameters such as temperature and pressure in the reaction kettle to ensure the stable and orderly progress of chemical reactions.

• Efficient and Energy-saving Design: The module efficiency is as high as 95%, which significantly reduces energy consumption. In the long-term operation process, it can save a lot of energy costs for enterprises, conforming to the current development trend of industrial energy conservation and emission reduction.

• Automatic Identification and Rapid Configuration: Has the function of automatic module identification. After the module is powered on and started, the CPU can quickly read special boot parameters from its own EEPROM, enabling the system to quickly complete the identification and configuration process, greatly shortening the time required for system startup and debugging, and effectively improving work efficiency.

• Low CPU Overhead Operation: Adopts the method of direct memory access to the main memory, with CPU overhead less than 4 during operation, which greatly reduces the occupation of controller CPU resources, makes the entire system run more efficiently, and can handle multiple complex industrial control tasks at the same time.

• Program Upgradability: Built-in dedicated communication processing chip, whose firmware program supports upgrading through the system bus, facilitating users to expand and optimize the module functions according to actual needs and technological development in the subsequent use process, extending the service life of the equipment and improving equipment adaptability.

• Comprehensive Protection Functions: Equipped with multiple protection mechanisms, such as DC overcurrent protection, AC overvoltage and undervoltage protection, AC phase imbalance protection, and 12-pulse system imbalance protection. In the electrolytic industry, it can effectively protect equipment from the impact of abnormal fluctuations in current and voltage, ensuring the safety and stability of the production process. At the same time, it also has a DC grounding fault detection function, which can be detected by a 3-volt voltmeter to timely detect and deal with potential fault hazards.

• Electrolytic Industry: In the electrolytic production process of metals such as copper and zinc, PPD113B01-20-111000 can realize IDC current step compensation to ensure the smooth progress of the electrolytic process when the current changes; its comprehensive protection functions such as overcurrent, overvoltage, and phase imbalance can effectively protect expensive electrolytic equipment, and strongly ensure the continuity and stability of production.

• Power Industry: Can be applied to the power distribution and monitoring system of power plants, accurately monitor and control parameters such as current and voltage to ensure stable power supply. In the substation scenario, it can monitor the operating status of various power equipment in real time, timely discover and handle abnormal situations, and ensure the safe and reliable operation of the power grid.

• Metallurgical Industry: In production links such as steelmaking and steel rolling, it performs high-precision collection and control of parameters such as temperature, pressure, and flow of equipment. Taking the temperature control of the steelmaking furnace as an example, it can be accurately adjusted to ensure the quality of molten steel and the smelting effect; in terms of pressure control of the hydraulic system of the rolling mill, it can ensure the stability and precision of the steel rolling process.

• Manufacturing Industry: Widely used in various manufacturing production lines to monitor the operating status of production equipment in real time and collect data. In the automobile manufacturing production line, it can monitor the operating parameters of robots and the status of the power system of equipment, and improve production efficiency and product quality through precise control.

• Port and Logistics: Used for the control and monitoring of port cranes, conveyor belts and other equipment. Through accurate signal collection and processing, it realizes efficient operation and automatic control of equipment, and improves the efficiency of cargo loading, unloading and transportation. For example, it can precisely control the lifting speed and position of cranes to ensure the safe lifting of goods.
