E-commercemultifunction Packaging Machine

〖Introduction 〗

 Combined packaging machine: to complete two or more automatic packaging processes of equipment through the combination of the packaging machine with different functions, which can meet different packaging requirements according to the actual situation.

〖equipment characteristics 〗

〓 Box sealing machine: automatically complete the box sealing and express delivery sheet process.

〖machine parameters 〗

〔〔Pillow packaging machine + shrinking machine——HS-101-ZS〕〕

『Pillow packaging machine』

Power supply: 220V, 50 / 60Hz

Power: 4.75KW

Packaging Film Width: Max.590mm

Bag length and size: 80-450mm

Wide material size: 20-200mm

High content size: 5-90mm

Packaging speed: 30-175 pack / min

Film type: POF

Machine size: L490 * W113 * H150cm

Weight: 1,200 kg

『shrinking machine』

Power supply: 380V, 50 / 60Hz

Power: 13.5KW

Dimensions: L2600 * W600 * H1750mm

Weight: 380kg

〔〔Pillow packaging machine + shrinking machine——HS-102-ZS〕〕

『Pillow packaging machine』

Power supply: 220V, 50 / 60Hz

Power: 4.75KW

Packaging Film Width: Max.590mm

Bag length and size: 60-320mm

Wide material size: 10-200mm

High content size: 5-35mm

Packaging speed: 30-150 pack / min

Film type: PVC, POF and other thermal shrinkage film

Dimensions: L480 * W117 * H150cm

Weight: 760kg

『shrinker』

Power supply: 380V, 50 / 60Hz

Power: 13.5KW

Overall dimension: L260 * W60 * H170cm

Size of furnace channel: L230 * W25 * H20cm

Weight: 380kg

〔〔L-type sealing machine + thermal shrinkage machine——HS-FQ550+HS-SS4020C〕〕

『Seal cutting machine』

Power supply: 220V, 50 / 60Hz

Power: 1.5KW

Use gas source: 5-7 kg / cubic meter 2 cm 3

Packaging speed: 15-30bags / min

Package size L + H: <600mm (H <150mm)

Package size W + H: <500mm (H <150mm)

Sealing knife size: L650 * W550mm

Machine size: L1750 * W900 * H1450mm

Overall weight: 350kg

Applicable shrinkage film: POF, PE

『shrinker』

Power supply voltage: 380V, 50 / 60Hz

Power: 9KW

Size of shrinkage furnace: L1200 * W400 * H200mm

Product size: W350 * H150mm

Delivery speed: 0-15m / min

Delivery material: mesh belt, chain roller, Teflon

Delivery load: Max.20kg

Machine size: L1600 * W560 * H660mm

Overall weight: 80kg

Application: POF, PVC, PE, PP

〔〔Vertical sealing machine + one-click paste single machine——HS-FQ5545C+HS-TB101〕〕

『Seal cutting machine』

Power supply: 220V, 50 / 60Hz

Power: about 3KW

Packaging speed: 15-30bags / min

Sealing knife size: L550 * W450mm

Opening size: 180mm

Air pressure: 0.5 MPA

Delivery load: Max.15kg

Applicable shrinkage applicable: PE

Machine size: L1630 * W900 * H1470mm

Overall weight: 300kg

『Paste machine』

Type: research control step motor control

Order speed: 40-100 pieces / min

Order accuracy: ± 3mm

Exit speed: 25 m / min

Conveyor belt speed: 25 m / min

Conveyor belt length: 1,000 mm

Height: 600-850mm

Host direction: right and left

Carton Height: Max.300mm

Carton width: Max.300mm

Overall dimension: L1000 * W500 * H1200mm

Weight: 100kg

Power: 400W

Power supply: 220V, 50 / 60Hz

Operating ambient relative temperature: 0 to 50℃

Use of relative humidity: 15~90%

〔〔Vertical sealing machine + thermal shrinkage machine——HS-FQ5545C+HS-SS5030〕〕

『Seal cutting machine』

Power supply: 220V, 50 / 60Hz

Power: about 3KW

Packaging speed: 15-30bags / min

Sealing knife size: L550 * W450mm

Opening size: 180mm

Air pressure: 0.5 MPA

Delivery load: Max.15kg

Applicable actile applicable: POF

Machine size: L1630 * W900 * H1470mm

Overall weight: 300kg

『shrinker』

Power supply specification: 380V, 50 / 60Hz

Power:: 11KW

Overall machine size: L1600 * W660 * H760mm

Delivery speed: 0-15m / min

Delivery material: mesh belt, chain roller, Teflon

Delivery load: Max.20kg

Size of shrinkage furnace: L1200 * W500 * H300mm

Product size: W450 * H250mm

Overall weight: 90kg

Applicable shrinkage film: PVC, POF

〔〔Touch screen type stick single machine + e-commerce box sealing machine——HS-TB102+HS-FX4030-A〕〕

『cartoning sealing machine』

Power supply voltage: 220V, 50Hz

Seal length range: 130mm-unlimited

Seal width range: 80-300mm

Seal height range: 90-400mm

Applicable width of the adhesive tape: 30-50mm

The reserved length of the tape on both sides: within 6cm

Drive mode: left and right drive

Applicable tape type: PVC, BOPP

Overall dimension: L152 * W63 * H139cm

『Paste machine』

Power supply specification: 220V, 50 HZ

Order speed: 25-30 times / min

Order accuracy: ± 1mm

Face single length range: 20-300mm

Face single width range: 30-120mm

Carton Height: Max.300mm

Carton width: Max.400mm

Overall dimension: L150 * W68 * H144cm

Overall weight: 200kg

Note: As the machine is constantly updated, the specific parameters are subject to the physical or contract.
