China aramid paper high temperature resistant flame retardant insulation paper YT 510

Minshida aramid paper Features: Calended intermediate aramid insulating paper, with high dielectric strength, mechanical strength, flexibility and resilience, thickness from 0.05mm to 0.76mm.

Application: Electrical insulation, used in almost all known occasions that require electrical insulation, can be short-term overload operation, strong overload resistance.

Metastar aramid paper is a special paper made of pure aramid fiber, which has the characteristics of high strength, low deformation, high temperature resistance, chemical corrosion resistance, radiation resistance, flame retardant and excellent electrical insulation, etc., and is widely used in aerospace, transportation, energy and power fields.

Metastar aramid paper due to its good mechanical properties and high temperature insulation characteristics, according to the use can be divided into electrical insulation aramid paper (YT510, YT516, YT511, YT564, YT56) and honeycomb core material aramid paper (YT822A, YT822, YT836) two categories.

Metastar's aramid paper for electrical insulation has a UL certified temperature resistance grade of 210 ° C, and the mechanical and electrical products made of it can reach a temperature resistance insulation grade above H (180 ° C). Because the aramid paper does not deform or melt at high temperature, it improves the ability of mechanical and electrical products to temporarily withstand overheating and overload. And the use of aramid paper as insulation material can make mechanical and electrical products compact and durable, and its size and weight are greatly reduced.

Aramid insulating paper is mainly used for: transformer coil, winding layer insulation materials, insulation sleeves, components, wires and joints with insulation materials; Motor and generator coil winding, slot, phase to phase, turn to turn, line terminal insulation materials; Cable and wire insulation, nuclear power equipment insulation materials, etc., the representative products are dry transformer, locomotive traction motor, mine motor, microwave oven transformer.

Metastar honeycomb paper is mainly made of aramid paper honeycomb core structure, which has the characteristics of light weight, impact resistance, high strength, aging resistance, etc., mainly used in wide-frequency wave transmission materials and large rigid secondary stress structural components
