Product Description
HC-A006 China high quality notebook LED Digital Ultrasound Scanner
I. Specifications
*Model:HC-A006 China high quality notebook LED Digital Ultrasound Scanner
*Image multiplying factor:3.5MHz/R60 convex array probe: x0.8;x1.0,x1.2,x1.5,x1.8, x2.0( 6 modes)x0.8;x1.0(display penetration depth)
*E-zoom:Magnify 2 times of real time image
*Dynamic range:0~120db adjustable
*Gray scale:256 levels
*Permanent storage:128 images
*Output interface:USB port
*Standard configuration:Ultrasound machine with 3.5Mhz convex array probe and power adapter
*Annotation function:Hospital name;patient’s name, age and gender; Body marks(with probe’s position);Full-screen character annotation;Real-time clock display
*Focus position:Dynamic electron focusing
*Frequency conversion:2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0Mhz
5 periods of frequency conversion
Frequency range applies
5.5MHz/6.0MHz/6.5MHz/7.0MHz/7.5MHz can match high frequency probe
*Puncture guide:3.5MHz convex array probe can display punture guide in B mode
*Gain control:8segments TGC and overall gain can be adjusted respectively
*Capacity cine loop:Real time display 256 consecutive images which are moemorized successively
II.Standard Configuration:
1..One convex array probe:F=3.5MHZ
2.One host machine
3.One power adapter
4.USB port
5.11.1 V 2500MAH Li battery
Other parameters
|
Designation |
Performance |
|
Displayer |
10.4 inch LCD color display |
|
≤±20% |
|
|
The battery pack works continuously |
≥1 hour |
|
Input power |
AC220V±22V,1.5A |
|
Gross weight |
about 3.62 kg |
|
Host weight |
about 2.67 kg |
|
Host appearance size |
300×245×60 (length × width × height)(mm3) |
|
The outer packing size |
365×255×70 (length × width × height)(mm3) |
III.Pictures :
A: Firstly we confirm product details and then send the Proforma Invoice,
You make payment to us through Trade Assurance or T/T, Western Union or MoneyGram,
after we confirm your payment then ship the product to you once finished production.
2. For HC-A006 China high quality notebook LED Digital Ultrasound Scanner product, What’s the minimum order quantity (MOQ)?
A: For disposable material,We have our own MOQ,For our HC-A006 China high quality notebook LED Digital Ultrasound Scanner, our MOQ:1pc,
3. What is your warranty?
A: For most products the warranty is for 12 months, some products we provide 18 months warranty.
For HC-A006 China high quality notebook LED Digital Ultrasound Scanner , we provide 12 months warranty.
4. What’s your delivery time?
A: Generally it is 5 working days if goods in stock. within 10 working days if the goods need production,
5. How to ship the product?
A: The shipping way normally depand on your quantity,total CBM and weight.
We have our own shipping company to provide best shipping cost and efficient way.
