Module spare parts　FLN3524A

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Temperature Rev A to J: -20 to +70°C (-4 to +158°F) Rev K and later: 0 to +70°C (32 to +158°F) -40 to +70°C (-40 to +158°F) Relative Humidity 5 to 95% (noncondensing) 5 to 95% (noncondensing) Contamination Suitable for use in Class G3 (Harsh) environments as defined in ISA Standard S71.04, based on exposure testing according to EIA Standard 364-65, Class III. 10 PSS 41H-2S233 Physical Specifications FBM233 Field Device System Integrator Module, 10/100 Mbps Ethernet, Redundant Physical Specifications Mounting The FBM233 mounts on a Modular Baseplate. The Modular Baseplate can be mounted horizontally or vertically on a DIN rail, or mounted horizontally in a 19-inch rack using a mounting kit. Refer to PSS 31H-2SBASPLT for details. Dimensions ? Height: 102 mm (4 in) 114 mm (4.5 in) including mounting lugs ? Width: 45 mm (1.75 in) ? Depth: 104 mm (4.11 in) Part Number P0926GX Weight 284 g (10 oz) approximate, per module Cables ? From Module to Hub/Switch/Device 1 m (3.3 ft) to 100 m (330 ft) ? Connectors RJ-45 ? Null Hub Adapter P0971PK PSS 41H-2S233 11 FBM233 Field Device System Integrator Module, 10/100 Mbps Ethernet, Redundant Ethernet Switches for Use with FBM233 Ethernet Switches for Use with FBM233 DIN Rail Mounted 5-Port 10/100 Base TX Switch The 5-port 10/100 base TX Ethernet switch (P0972WE) is Din rail mounted and available for use with the FBM233. You can connect up to four Ethernet devices using this 5-port switch. Additionally, multiple switches can be interconnected to connect up to 64 devices to a single FBM233. For detailed physical and electrical specifications, refer to Model SFNB 5TX 2891001 at /us/products. Figure 2. 5-Port 10/100 Base TX DIN Rail Mounted Ethernet Switch (P0972WE)
