Product Description
Product Description
High weir mining equipment barite iron copper ore mineral zircon sand gravity separator spiral classifier for sale
Spiral classifier is one of the classifying equipment in mineral processing. It is suitable for classifying materials in the mineral processing plant as well as the desliming and dehydrating in the mineral washing operating process and widely applied to separate the particles into a number of products graded according to size in the complete closed loop together with ball mill in the mining industry.
It is widely applied to the mining industry, such as separating light particles from heavy particles in the gravity separation process, separating fine particles and liquid from coarse particles in the metal ore processing, and separating the slurry or liquid from solid particles in ore processing plant.
It is widely applied to the mining industry, such as separating light particles from heavy particles in the gravity separation process, separating fine particles and liquid from coarse particles in the metal ore processing, and separating the slurry or liquid from solid particles in ore processing plant.
Model | Screw diameter (mm) | Sink length (mm) | Screw RPM (r/min) | Capacity(t/d) | Motor Power (Kw) | Total Weight (t) | ||||
return sand | overflow | Drive | Lifting | |||||||
FG-5 | 500 | 4500 | 8-12.5 | 135-210 | 32 | 1.1 | / | 1.9 | ||
FG-7 | 750 | 5500 | 6-10 | 340-570 | 65 | 3 | / | 3.1 | ||
FG-10 | 1000 | 6500 | 5-8 | 675-1080 | 110 | 5.5 | / | 4.9 | ||
FC-10 | 8400 | 675-1080 | 85 | 7.5 | / | 6.2 | ||||
FG-12 | 1200 | 6500 | 4-6 | 1170-1870 | 155 | 7.5 | 2.2 | 8.5 | ||
FC-12 | 8400 | 1170-1870 | 120 | 7.5 | 2.2 | 11 | ||||
FG-15 | 1500 | 8300 | 4-6 | 1830-2740 | 235 | 7.5 | 2.2 | 12.5 | ||
FC-15 | 10500 | 1830-2740 | 185 | 7.5 | 2.2 | 16.8 | ||||
2FG-15 | 8300 | 2280-5480 | 470 | 15 | 4 | 22.1 | ||||
2FC-15 | 10500 | 2280-5480 | 370 | 15 | 4 | 30.7 | ||||
FG-20 | 2000 | 8400 | 3.6-5.5 | 3290-5940 | 400 | 11-15 | 3 | 20.5 | ||
FC-20 | 12900 | 3210-5940 | 320 | 15-18.5 | 3 | 28.5 | ||||
2FG-20 | 8400 | 7780-1180 | 800 | 11X2 | 5.5 | 35.5 | ||||
2FC-20 | 12900 | 7780-1180 | 640 | 18.5X2 | 5.5 | 48..7 | ||||
FG-24 | 2400 | 9130 | 3.67 | 6800 | 580 | 22 | 3 | 28.7 | ||
FC-24 | 14130 | 6800 | 490 | 22 | 4 | 41 | ||||
2FG-24 | 9130 | 13600 | 1160 | 18.5X2 | 5.5 | 45.8 | ||||
2FC-24 | 14130 | 13700 | 910 | 30X2 | 7.5 | 67.9 | ||||
FG-30 | 3000 | 12500 | 2-4 | 11650 | 890 | 30 | 4 | 37.6 | ||
2FG-30 | 12500 | 23300 | 1785 | 30X2 | 7.5 | 78 | ||||
2FC-30 | 14300 | 23300 | 1410 | 30X2 | 7.5 | 89.8 | ||||
Product Details
Reinforced Tank And Base
Strong Stability, long service life
Seamless steel tube spindle
Strong rigidity, strong torsion, no deformation.
High Quality Transmission System
Copper core motor, high quality reducer, stainless steel bearing, stable and reliable running.
Thickened Wear- Resistant Blade
Wear resistance iron material, removable design, easy to replace
Products Application
Spiral classifiers are widely used in the distribution of ore in closed circuits with ball mills, grading ore and fine slit in gravity mills, grading granularity and flow of metal ore dressing, and de-sliming and dehydrating in washing.
Working Principle
Different solid granularities have different gravity and thus have different dropping speed. The fine ore granularities floating in the water will overflow and the big ones will sink to the bottom and discharge from the upper part by spiral pushing.
It can filter the granularities from the machine and then spin the rough particles to charging part by spiral vane and discharge the fine granularities from the overflow pipe. The base of the machine adopts a channel steel and the body adopts welded steel plate. The water inlet of spiral axle and axle head adopt pig iron cover for wear proofing and long life operation. The lifting equipment has two types, manual control and electric control.
Related Products：
Sand washer is widely used for the washing of the material sand quarry, mining, building
materials,transportation, chemical industry, water conservancy and hydropower, concrete mixing station,etc.
According to different kind of washing type, we have :
Spiral sand washing machine:
Wheel type sand washing machine:
materials,transportation, chemical industry, water conservancy and hydropower, concrete mixing station,etc.
According to different kind of washing type, we have :
Spiral sand washing machine:
Wheel type sand washing machine:
Company Profile
Hengchang is a company integrating industry and trade. Its main business is the sale of jaw crushers, drying equipment, and mineral processing equipment. We have our own factory, professional production team, quality control team, 10 years of export experience and many loyal customers. We have experience in exporting products to Southeast Asia, Australia, Europe, South America and Africa, and have gained a good reputation. At the same time, our excellent product quality and best service have won the trust of customers all over the world. Many of our products have obtained CE certification, and most of our partner factories have ISO9001 and IEC certifications. Some have also obtained etification. We believe that our company is your good choice, because we respond quickly to your enquiry, and we will reply you within 4 hours. Our experienced English-speaking trading staff will listen to your requirements and choose the right products for your market according to your requirements.
The Customer Site
We have provided the log washer for many customers in Sudan,Mali, Mozambique, Nigeria, Suriname, Ghana, South Africa,Uganda, Zambia, Tanzania, Angola, Canada, Austrialia, Chile, Peru,ect. For Alluvail gold washing plant, coltan ore mining plant,diamond washing plant, Iron ore washing plant,ect.
Customer Visit & Our Service
Before-sale services:
We guide customers to choose the best and applicable device; provide the advanced, energy-saving and practical technological processes, as well as we are responsible for the planning and design of the site.
Sale services:
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
After-sale services:
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.
Solemn Promise:
The quality guarantee period of machines is one year except the wearing parts
Tips:
The prices in the web only to be reference,according to raw material's price fluctuations; Specific price is subject to the
negotiation.
Sale services:
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
After-sale services:
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.
Solemn Promise:
The quality guarantee period of machines is one year except the wearing parts
Tips:
The prices in the web only to be reference,according to raw material's price fluctuations; Specific price is subject to the
negotiation.
Product & Packaging
Packaging Details:
Normally the machines are taken apart before delivery and are packed by suitable packing ways, the packing ways are as below: Nude packing. Bundle packing. Grass rope packing. Water proof packing. Wooden pallets packing. Wooden box or carton box packing.
Delivery Time:
Delivery Time:
We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.
RFQ
Q:Why we believe in Gongyi Hengchang company?
A: 1.More than 28 years’ experience.
2.Hengchang is the leading professional supplier of solution, equipment’s and service for crushing and grinding industry.
3.Products achieved ISO9001:2000 quality management certificate and EU CE certificate.
.
Q:Delivery time?
Q:Delivery time?
A:The lead time is 10-20 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.
Q:Payment terms ?
A:Accepted Payment Type: T/T, L/C, Western Union, Cash and so on. After sign
the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
Q:What will you do if the machine is broken down?
A:The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q:What should i do if I want to get a best quotation?
A: If you want a suitable type for you, please let us know your material and capacity.
