Customized 6.5hp Large Capacity Big Portable Inclined Big Dip Angle Sidewall Rubber Belt Conveyor for Coal Cement Industry Stone

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Customized 6.5hp Large Capacity Big Portable Inclined Big Dip Angle Sidewall Rubber Belt Conveyor for Coal Cement Industry Stone

Sidewall Rubber Belt Conveyor (also called large dip corrugated belt conveyor) with a large inclination (90 degrees vertical) transport.

So that it is ideal equipment for achieving large angle conveying. Widely adopted in underground mining projects, open pit mining, large dump trucks and other parties.

Product Application

Large angle belt conveyor can be used for bulk materials such as coal, coke, sand, aggregate, sand, broken glass, asphalt raw materials, stone, fertilizer, lime, etc., and it can be transported in the working environment humidity range of -15 °C to +40 °C.
Various bulk materials with a specific gravity of 0.7-3.0t/m3.The corrugated belt conveyor can transport a variety of bulk materials in horizontal, inclined, vertical and variable angle directions, from coal, ore, sand to fertilizer and grain.

The material size is not limited and can range from very small particle sizes to large particle sizes of 400 mm. The delivery rate can range from 1 m3/h- 6,000m3/h.

Product Features

Main features of large angle belt conveyor:

1.Save floor space and save investment. Simple structure, reliable operation and low noise. low energy consumption;
2.Large conveying capacity, strong versatility, convenient maintenance, parts such as rollers and ordinary belt conveyors;
3.Conveyor inclination: 0°-90°;
4.Easy to interface with other equipment. Easy to arrange;
5.Wide range of applications: metallurgy, mining, docks, environmental protection, food, chemicals, building materials, etc.

Working Principle

Mobile Belt Conveyor consists of main body of metal frame, pulleys, rollers, belt, motor and reducer, control cabinet.

Belt is looped around the head pulley, tail pulley and rollers. When head pulley is powered by electric motor, the belt slides across the rollers meanwhile moving the product on the top of the belt, and the machine is portable, this will save the labor cost a lot.

Belt width	Sidewall height	Cleat pitch	Slant angle
Belt width	Sidewall height	Cleat pitch				30°	40°	50°	60°	70°	90°
mm	mm	mm	Capacity(m3/h) Speed of belt=1m/s
500	120	252	52	40	32	26	21	-
500		160	378	65	52	42	34	28	17
650	120	252	78	60	48	39	32	-
650		160	378	73	56	45	36	30	-
800	120	129	99	76	60	49	40	-
800		200	378	148	114	91	74	61	37
1000	160	378	129	99	79	64	52	-
1000		240	504	229	176	141	-	-	-
1200	160	252	223	180	144	117	96	59
1200		240	378	342	280	224	183	149	91
1400	200	252	299	231	185	151	123	75
1400		240	378	422	345	276	225	184	113

Customer Visits & Exhibition Souvenirs

Company Profile

Hengchang headquarters is located in the industrial park in Gongyi City. It covers a total area of 150,000 square meters,including 100,000 square meters of standarized workshop. There are more than 200 sets of various large and medium-sized metal processing lathe, riveting machine, welding equipment and assembly equipment. We have more than 300 workers, including more than 20 middle and senior technicians. Hengchang is mainly focus on 4 series products: stone crusher machines, sand making equipment,powder grinding mills, mineral processing equipment and their spare parts. Every year, Hengchang can turn out 1,000 sets of crushers and10,000 tons of crusher parts.

Customer Case

Our machine has been sold to Germany, Australia, Japan, Mexico, Philippines, Indonesia, Russia, Uganda, Uzbekistan, Zimbabwe, etc.
And our products are well received by customers. Welcome to inquiry!

Our Service

Before-sale services:

We guide customers to choose the best and applicable device; provide the advanced, energy-saving and practical technological processes, as well as we are responsible for the planning and design of the site.
Sale services:
Products must be inspected strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.
After-sale services:
Our Company will send professional engineers to guide device installation, debug and train operators until customers are fully . Moreover, we will design and produce machines according to the special requirements of customers.
Solemn Promise:
The quality guarantee period of machines is one year except the wearing parts
Tips:
The prices in the web only to be reference,according to raw material's price fluctuations; Specific price is subject to the negotiation.

Packing &Delivery

Packaging Details:

Normally the machines are taken apart before delivery and are packed by suitable packing ways, the packing ways are as below: Nude packing. Bundle packing. Grass rope packing. Water proof packing. Wooden pallets packing. Wooden box or carton box packing.
Delivery Time:

We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.

RFQ

Q:Why we believe in Gongyi Hengchang company?

A: 1.More than 28 years’ experience.

2.Hengchang is the leading professional supplier of solution, equipment’s and service for crushing and grinding industry.
3.Products achieved ISO9001:2000 quality management certificate and EU CE certificate.

Q:Deliverytime ?
A: The lead time is 10-20 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.

Q: Payment terms ?

A: Accepted Payment Type: T/T, L/C, Western Union, Cash and so on. After sign
the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.

Q: What will you do if the machine is broken down?

A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.

Q:What should i do if I want to get a best quotation?

A:If you want a suitable type for you, please let us know your material and capacity.
