CNC cutters multi heads price cheap glass cutter machine for glasses
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
CNC cutting machinery price glass cutter machine automatic
-
CNC cutting machinery heavy duty glass cutting glass cutter price
-
Diamond tool high speed cnc machine cut glass for 2mm,4mm,8mm mirror cutting cnc router
-
CNC Glass Edge Grinder With Double Wheels Mini Glass Edge Polishing Machines for Grinding Polishing Glass Mirror Bevel Edge
-
CNC Glass Edge Grinding Machine With Double Wheels Automatic Used Glass Edge Polishing Machines for Glass Mirror Bevel Edge
-
Double Glass Edge Machine For Grinding Irregular Shape Glass Mirror Small CNC Glass Grinding Polishing Machine
Product Description
CNC cutters multi heads price cheap glass cutter machine for glasses
Product Description
Features:
2.Three axises adopt taiwan brand linear guide rails with high precision.
3. Z axis adopts imported Germany or Taiwan made ball screw, so high precision and long life time using are assured.
4. X and Y axis is transmitted by helical rack and pinion. This makes the machine work faster and has larger cutting force compared with ball screw transmission.
5.Well compatibility: CAD/CAM designing software, such as type3/castmate/wentai/artcam, etc.
6. Our cnc glass cutting machine has the function of re-carving after break point or power failure and it can estimate the processing time.
7. Manual/automatic oil-injection system allows the machine maintenance mush easier.
Specification
Model | SKQ-1010 | SKQ-1313 | SKQ-1325 | Other size customized | |||
Working area (X*Y) | 1000*1000mm | 1300*1300mm | 1300*2500mm | ||||
Body structure | Thicken steel made | ||||||
X, Y Structure | Taiwan rack and pinion | ||||||
rails | Taiwan HIWIN square rails | ||||||
Glass thickness | 1-19mm | ||||||
Cutting heads | 6 heads ( can be customized 1-14 heads) | ||||||
Max Moving Speed | 40000mm/min | ||||||
XYZ traveling positioning accuracy | ±0.01mm | ||||||
XYZ re-positioning accuracy | ±0.01mm | ||||||
Voltage | 220v/single phase ,50hz or other can be customized | ||||||
Drive type | Stepper motors and Leadshine drivers | ||||||
Working Dictate | G Code | ||||||
Operating system | MACH3 control system | ||||||
Auto oil lubricator | included | ||||||
software | Artcam 8.1(free supply) | ||||||
After packed size | 1.78*1.63*1.8M | 2.1*1.8*1.89M | 3.25*2.2*1.95M | ||||
G.W | 700KGS | 870KGS | 1200KGS | ||||
