Product Description
Horizontal Type With Cart Bamboo Biomass Briquette Wood Branch Log Charcoal Making Carbonized Stove Machine
Operation steps of the Horizontal Type With Cart Bamboo Biomass Briquette Wood Branch Log Charcoal Making Carbonized Stove Machine:
1. Preparing the material; if it's the wood, please make sure the size is not with big different;
2. Open the furnace door, and put the mateiral inside directly; or you can put the mateiral on the rail car to send the material into the inner pot.
3. Seal the furnace, and check the valves and other things, make sure the furnace is ok before firing.
4. FIre the furnace and to make the charcoal. This step, there is the combustible gas to produce and this gas can be sent to the bottom of the fire mouth to let the machine heat.
5. After the charcoal finished and cooled, then use the rail car to delivery the charcoal out. Then all the steps are finished.
Main data of the Horizontal Type With Cart Bamboo Biomass Briquette Wood Branch Log Charcoal Making Carbonized Stove Machine:
Type | Horizontal Airflow type |
|
Model | WTH150-1 | WTH150-2 |
Volume | 5.3CBM | 8CBM |
Raw material | wood log, wood branch, timber, biomass briquette, jute stick etc biomass material |
|
Capacity | 800-1000kg/day for charcoal making | 1.2-1.5t/day for charcoal making |
Inner pot inside size | 1.5*3m | 1.5*4.5m |
Inner pot steel thickness | 10mm boiler steel |
|
Machine frame material | Q235R |
|
Machine size | 3.5*2.1*2.2m | 5*2.1*2.2m |
Machine consists | inner tank, insulation, furnace door, rail car , combustible gas reburning pipe, dehumidifying buffer tank, burner, exhaust pipe, and thermometer. and the purification tank system |
Raw material and charcoal getting from the Horizontal Type With Cart Bamboo Biomass Briquette Wood Branch Log Charcoal Making Carbonized Stove Machine:
All kinds of wood, log, branch, bamboo, coconut shell, jute sticks, biomass briquette etc can be used for this machine to make the charcoal.
Related machines for the carbonizing system, and you can tell us your material and capacity, we can give you the best project:
1. Hoist Gas flow type carbonization furnace----Mainly using wood log, wood briquette, bamboo, coconut shell, corn cob, cotton stalk, wood branch etc.
2. Sawdust rice husk carbonization machine----This type is same with the new type, but this type capacity is smaller than the new type.
3. Rotary continuous type carbonization machine-----Mainly using sawdust, rice husk, wood chips, bamboo chips, coconut shell chips etc biomass materials.
4. Square carbonization furnace-----Mainly using wood briquette, this is the traditional type.
Packing information:
FOr the machines, we pack it in the standard container.
