Low Price Walnut Shell and Kernel Separator Machine Nut Vibration Sieve Price

It is used for separating almonds, apricot kernels, walnut kernels and walnut crusts. It is a supporting equipment of sheller. This machine is composed of feeding hopper, sieve body, fan and frame, eccentric transmission mechanism and so on. It can sift 500 kg of material per hour. It has high output, strong sieving force, quick separation of almond and shell, simple and convenient operation.

Working principle

After the apricot core is shelled by the apricot core sheller, the apricot kernel and the apricot shell are separated by the shell kernel separator. It can also be used to separate walnut shell and kernel after shelling. This machine makes use of the difference of the proportion of shell and kernel and the suspension speed, and makes use of the upward air flow through the particle gap to separate shell and kernel. Simple and easy to operate; has a small footprint, and can be easily assembled into a production line

Features of walnut screening machine

(1) The structure is simple and compact, the operation is simple
(2) The movable sieve plate can be replaced, there are more choices, and the nuclear types with different specifications can be screened.
(3) The machine has a long service life, is not easy to block, and has high work efficiency.
(4) The mesh screen has a large effective area and can be fully worked and effectively screened.
(5) The design has reasonable breakage rate and is the most ideal nuclear processing equipment at present.

(6)Simultaneous screening of multiple levels and a variety of nut
(7) The machine can be matched with other machines to facilitate the formation of the production line, with higher work efficiency and higher output.

Technical parametrs
