Product Description
Product Overview
Commercial Walnut Nut Cracking Shelling Hulling Sheller Huller Black Walnut Cracker Machine
Walnut peeling machine is mainly used for hard peeling of walnuts. Different walnut
varieties have different yields and kernel integrity rates. One is that the structure adjusts the motor speed to make the speed
and internal wind power suitable. The other is to adjust the internal gap to achieve an ideal shelling effect.
varieties have different yields and kernel integrity rates. One is that the structure adjusts the motor speed to make the speed
and internal wind power suitable. The other is to adjust the internal gap to achieve an ideal shelling effect.
PRODUCT SPECIFICATIONS
Model | RX-TK400 |
Capacity | 300-400kg/h |
Suitable | WALNUT |
Power | 1.1kw |
Weight | 260kg |
Dimension | 1300*800*1500mm |
MACHINE ADVANTAGES
What can we do for you?
1. We can make a suitable plan according to your production requirements
2. We can customize the motor or other accessories according to your local requirements
2. We can customize the motor or other accessories according to your local requirements
MACHINE STRUCTURE
The walnut peeling machine consists of a frame, a fan, a rotor, a single-phase motor, a screen (two types of large and small), a hopper, a vibrating screen, a V-belt wheel and a driving V-belt, etc. After the machine is running normally, put the walnuts into the hopper quantitatively, evenly and continuously. The walnuts are broken under the repeated blows, frictions and collisions of the rotor. The walnut kernels and broken shells pass under the rotating wind pressure and blows of the rotor. A screen with a certain aperture (a large-hole screen is used for the secondary threshing, and the small skin fruits after cleaning are replaced with a small-hole screen for the second peeling) and separated. Walnut shells and grains are blown out of the body by the blowing force of the rotating fan, and the heavier fruits are screened and sorted through a vibrating screen.
SALES AND SERVICE NETWORK
Walnut shelling machine is mainly used for hard shelling of walnuts. The variety of walnut
varieties is different, and the yield and the completeness rate of nuts are different. One is that the structure adjusts the motor
speed to make the speed of rotation and the internal wind force suitable. The other is to achieve the best shelling effect by
adjusting the internal clearance.
The utility model has the advantages of compact structure, simple operation, stable and reliable performance, high shelling
efficiency, low breaking rate of walnut kernel, good sorting and low loss rate. It can remove clods, stones, mulch and other
debris in the walnut kernel.
varieties is different, and the yield and the completeness rate of nuts are different. One is that the structure adjusts the motor
speed to make the speed of rotation and the internal wind force suitable. The other is to achieve the best shelling effect by
adjusting the internal clearance.
The utility model has the advantages of compact structure, simple operation, stable and reliable performance, high shelling
efficiency, low breaking rate of walnut kernel, good sorting and low loss rate. It can remove clods, stones, mulch and other
debris in the walnut kernel.
