Home > Products > Lifting Machinery > 100T Mobile Hydraulic Truck Crane STC1000S with 6 section boom
100T Mobile Hydraulic Truck Crane STC1000S with 6 section boom
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
heavy lifting crane 260 Ton Lattice Boom Crawler Crane SCC2600A for promotion
-
Heavy duty 100ton truck lifting crane STC1000S
-
China 50 Ton Lifting Truck Crane QY50KD with 50m Boom
-
Good quality 25 ton mobile crane truck prices china truck crane QY25K5D-1
-
China xuzhou good quality 25t truck crane QY25K5L sale
-
Mobile Truck Crane QY25K5D 25 ton Heavy Lifting Crane sale price
Product Description
Heavy duty 100ton truck lifting crane STC1000S
Products Description
* Excellent and stable chassis performance /chassis system
* Highly efficient, stable, energy-saving and adjustable hydraulic system
* Ultra long, super strong and highly sensitive load lifting capacity
* Safe, stable, advanced and intelligent electric control system
* Highly efficient, stable, energy-saving and adjustable hydraulic system
* Ultra long, super strong and highly sensitive load lifting capacity
* Safe, stable, advanced and intelligent electric control system
Specification
Type | Item | Parameter | ||
Capacity | Max. Lifting Capacity | 100t | ||
Dimension | Overall Length | 14000 mm | ||
Overall Width | 2800 mm | |||
Overall Height | 4000 mm | |||
Axle Distance | Axle-1,2 | 2080mm | ||
Axle-2,3 | 3925mm | |||
Weight | Overall Weight | 48000 kg | ||
Axle Load | Axle Load-1,2 | 22000 kg | ||
Axle Load-3,4 | 24000 kg | |||
Engine | ||||
Rated Power | 275kw/2100rpm | |||
Rated Torque | 1550N.m/1100-1400 rpm | |||
Traveling | Max.traveling speed | 80km/h | ||
Turning Radius | Min. Turning Radiums | 10.5m | ||
Min. Turning Radiums of Boom Head | ||||
Wheel Formula | ||||
Min. Ground Clearance | 320mm | |||
Approach Angle | 21° | |||
Departure Angle | 19° | |||
Max. Gradeability | 40% | |||
Fuel Consumption per 100km | ≤50L | |||
Main Performance | Temperature Range | |||
Min.Rated Range | ||||
Tail Slewing Radius of Swingtable | ||||
Boom Section | - | |||
Boom Shape | u-shape | |||
Max. Lifting Moment | Base Boom | 3300kN.m | ||
Full-extend boom | 1824 kN.m | |||
Full-extend boom+jib | - | |||
Boom Length | Base Boom | 12.26m | ||
Full-extend boom | 56m | |||
Full-extend boom+jib | 71.5m | |||
Outrigger Span(Longitudinal×Transversal) | 7.8*7.91m | |||
Jib Offset | 0°,15°,30° | |||
Working Speed | Max.single rope lifting speed of main winch (no load) | 123 m/min | ||
Max.single rope lifting speed of auxiliary winch(no load) | 123 m/min | |||
Full extension/retraction time of boom | 480/500s | |||
Full lifting/descending time of boom | 60/80s | |||
Slewing speed | 0~1.6 r/min | |||
Aircondition | Aircondition in up cab | Cooling/Heating | ||
Aircondition in low cab | Cooling/Heating | |||
Details Images
