New Mobile Hydraulic Crane 100t Truck Crane STC1000C
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Lifting Height 61m New 50t Truck Crane STC500T5
-
Lifting Height 62m New 60t Truck Crane STC600T5
-
100 Ton Mobile Truck Crane STC1000C
-
Crane Truck 100 Ton Truck Cranes STC1000C
-
ZOOMLION 55 ton lifting capacity truck crane ZTC551V/QY55V/ZTC551V552/QY55V552
-
China best quality 100ton truck crane STC1000C for sale
Product Description
Products Description
100 Ton Mobile Truck Crane STC1000C
Powerful Lifting Capacity.
The 100 ton truck crane has five-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 75t, full-extended boom length of 45m, jib length of 16m, max.lifting height including jib of 61m, reduce weight and improve safety significantly.
Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.
Excellent Traveling Performance
Double-axle drive is used to provide good trafficability and comfortableness under complex road condition; engine has the multimode power output function, which reduces power consumption; the use of tipping over early-warning technology provides high stable and safe operation.
Excellent Traveling Performance
Hydraulic system load feedback and constant power control is applied to provide strong lifting capacity and good micromobility.
Unique steering buffer design guarantees smooth braking operation.
Intelligent Electronic Control
Timely feedback of data information can achieve the monitoring of the overall working status in real time.
The Load Moment Limiter
Equipped with the comprehensive intelligent protection system is used with accuracy within 5%. The adoption of comprehensive logic and interlock control system ensures more safe and reliable operation.
More Safe Devices
Main and auxiliary winches are equipped with over roll-out limiter to prevent over rolling-out of wire rope.
Boom and jib ends are equipped with height limiters respectively to prevent over-hoisting of wire rope.
Hydraulic system is configured with the balance valve, overflow valve and two-way hydraulic lock etc., to ensure stable and reliable operation.
Specification
Type | Item | Parameter | ||
Capacity | Max. Lifting Capacity | 100t | ||
Dimension | Overall Length | 14000 mm | ||
Overall Width | 2800 mm | |||
Overall Height | 4000 mm | |||
Axle Distance | Axle-1,2 | 2080mm | ||
Axle-2,3 | 3925mm | |||
Weight | Overall Weight | 48000 kg | ||
Axle Load | Axle Load-1,2 | 22000 kg | ||
Axle Load-3,4 | 24000 kg | |||
Engine | ||||
Rated Power | 275kw/2100rpm | |||
Rated Torque | 1550N.m/1100-1400 rpm | |||
Traveling | Max.traveling speed | 80km/h | ||
Turning Radius | Min. Turning Radiums | 10.5m | ||
Min. Turning Radiums of Boom Head | ||||
Wheel Formula | ||||
Min. Ground Clearance | 320mm | |||
Approach Angle | 21° | |||
Departure Angle | 19° | |||
Max. Gradeability | 40% | |||
Fuel Consumption per 100km | ≤50L | |||
Main Performance | Temperature Range | |||
Min.Rated Range | ||||
Tail Slewing Radius of Swingtable | ||||
Boom Section | - | |||
Boom Shape | u-shape | |||
Max. Lifting Moment | Base Boom | 3300kN.m | ||
Full-extend boom | 1824 kN.m | |||
Full-extend boom+jib | - | |||
Boom Length | Base Boom | 12.26m | ||
Full-extend boom | 56m | |||
Full-extend boom+jib | 71.5m | |||
Outrigger Span(Longitudinal×Transversal) | 7.8*7.91m | |||
Jib Offset | 0°,15°,30° | |||
Details Images
