Hot Sale PLC Control Electrical Atomizer For Egg White

Hot Sale PLC control Electrical Atomizer For Egg White

1. Electric atomizer/ spray dryer atomizer / high-speed centrifugal atomizer

2. Stainless steel

3. electric type

Product Description

Rotary Atomizer Description

DPG-5 atomizer is the core of high-speed centrifugal spray drying, which includes high-speed motor, spindle, nylon block, large coupling plate, bearing and spray tray. It is not passed by connecting motor couplings and spindle motor of spindle and spindle of the atomizer, and the atomizer is the resonance region of the flexible shaft spindle at high speed rotation, and the atomizer spindle is stable. The high speed motor is equipped with water-cooled jacket and spray lubrication, and atomizer main shaft lubricating oil circulation. It has the advantages of high speed, smooth operation, small vibration, long life and simple operation. It can be widely used in high speed spray drying, liquid spray drying to powder materials and other industrial fields.

DPG-5 atomizer is a core component of centrifugal spray dryer; Our company specializes in the production of high-speed centrifugal atomizer, elected on the basis of absorbing foreign technology, based on independent research, computing, manufacturing, won the praise of domestic households. We could provide different specifications, different materials, different shapes of cntrifugal disk;

Rotary Atomizer Working Principle

After the filtering and heating, the air enters into the air distributor on the top of the drier. The hot air enters into the drying room in the spiral form and uniformly.

By passing through the high-speed centrifugal spray on the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads. Through the very short time of contacting the heat air, the materials can be dried into the final products.

The final products will be discharged continuously from the bottom of the drying tower and from the whirl separator. The waste gas will be discharged from blower.

The liquid material becomes very fine drops under the centrifugal force in the equipment, enlarging enormously the surface area of the material. It forms instantly the dried products once these drips contact with hot air. This process has advantages such as dry at high speed, high efficiency, easy operation, the output products keep the original quality, good fluidity, good solubility, high purity and environment friendly.

_{Centrifugal Atomizer Technical Parameter}

1.FEATURES

1) The speed can be adjusted steplessly, and the best speed can be selected according to the characteristics of the dried materials.

2) The high speed motor directly drives the atomizing disc, small vibration, uniform spray and low noise.

3) The power is self-adjusting with the load, the temperature rise is low and the performance is stable.

4) Compact structure, small size, light weight, easy to operate, clean and easy to maintain.

5) The composite electric atomizer adopts water cooling and air cooling at the same time, and selects grease lubrication and oil lubrication according to the needs, which is more suitable for working under high temperature environment. At the same time, it has the functions of water cut-off, AIR-OFF, over-current and over temperature alarm, with more stable performance.

2. APPLICATION

Chemical Industry: sodium fluoride (potassium), basic dye pigment, dye intermediate, compound fertilizer, formaldehyde silicic acid, catalyst, sulfuric acid, amino acid, white carbon black, etc.

Plastic resin: AB, ABS emulsion, urea formaldehyde resin, phenolic resin, rubber (urea) formaldehyde resin, polyethylene, polyvinyl chloride and so on.

Food industry: milk powder, prion, cocoa milk powder, milk replacer, egg white (yolk).

Pharmaceutical intermediates: Banlangen, ginsenoside, Ganoderma lucidum spore powder, Astragalus membranaceus, Yinhuang, ginkgo flavone, etc.

Food and juice: oats, chicken juice, coffee, instant tea, spices, meat, protein, soybean, peanut protein, hydrolysate, etc.

Sugar: corn syrup, corn starch, glucose, pectin, maltose, potassium sorbate, etc.

Ceramics: alumina, ceramic tile materials, magnesium oxide, talc, etc.
