Product Description
LPG Collagen protein spray dryer/ fish skin/pig skin spray dryer
I. Description of Collagen protein spray dryer:
LPG Centrifugal spray dryer is the widest used technology in the liquid shaping technology and in the drying industry. It is most suitable for producing powder, particle, or block solid products from materials of solution, emulsion, soliquoid and pumpable paste states. Therefore, when the particle size and distribution of the final products, their residual water contents, the stocking density and the particle shape meet the precision standards, the spray drying is one of the most desired technologies.
II. Features of Collagen protein spray dryer:
1. High speed of drying. After the spraying of he material liquid, the surface area of the material will be increased greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying needs only several seconds.
2. It is especially suitable for drying the heat sensitive materials. Its final products own the good uniformity, mobility, dissolving capacity. And the final products are high in purity and good in quality.
3. The production procedure is simple and the operational control is easy. The liquid with the moisture contents 40-60% (for special materials, the contents may reach 90%) can be dried into power or particle products once a time. After the drying, there is no need for smashing of sorting, so as to reduce the operation procedures in the production and enhance the purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition in a certain scope. It is very convenient to carry out the control and management.
III. Technical parameters of Collagen protein spray dryer
|
Type |
LPG |
|||||||
|
5 |
25 |
50 |
100 |
150 |
200-3000 |
|||
|
Inlet temperature |
≤ 350°C |
|||||||
|
Outlet temperature |
80-90°C |
|||||||
|
Evaporate capacity (Kg/h) |
5 |
25 |
50 |
100 |
150 |
200-3000 |
||
|
Driving type |
compressed air drive |
mechanical drive |
||||||
|
Rotate speed |
25000 |
22000 |
21500 |
18000 |
18000 |
15000 |
||
|
Diameter of Atomizer tray (mm) |
50 |
120 |
120 |
120 |
150 |
180-340 |
||
|
Heating source |
electricity |
electricity |
electricity +steam+fuel oil+coal gas |
electricity +steam |
electricity +steam+fuel oil+coal gas |
To be solved by users |
||
|
Electric-heating power (KW) |
9 |
45 |
60 |
81 |
99 |
|
||
|
Dried powder recovery rate (%) |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
||
|
Installation size |
A(mm) |
1000 |
1290 |
1730 |
2500 |
2800 |
According to practical needs |
|
|
B(mm) |
2100 |
3410 |
4245 |
5300 |
6000 |
|||
|
C(mm) |
2300 |
4260 |
4645 |
6000 |
6700 |
|||
|
φ D(mm) |
1060 |
1800 |
2133 |
2560 |
2860 |
|||
|
E1(mm) |
1050 |
1200 |
1640 |
2100 |
2180 |
|||
|
E2(mm) |
1050 |
1200 |
1640 |
2100 |
2180 |
|||
|
F(mm) |
750 |
1000 |
1250 |
1750 |
1970 |
|||
|
G(mm) |
530 |
1700 |
1750 |
1930 |
2080 |
|||
|
H(mm) |
530 |
1300 |
1800 |
2600 |
3050 |
|||
|
I(mm) |
530 |
1550 |
1600 |
1780 |
1960 |
|||
Note: All dimensions are for reference, they are depends on raw materials. Our factory has the right to change without prior notice.
IV. Flow chart of Collagen protein spray dryer
Our new factory is located in Zhenglu Industrial Park, Changzhou City, Jiangsu Province, China. It’s only 3 kilometers from downtown and it tightly close to east-ring elevated road of Changzhou and Hengshanqiao Exit of Shanghai-Nanjing Expressway.
Our company owns a 8000m2 composite comprehensive office building, for the 2 large-scale modern machinery heavy-duty manufacturing workshop which covers an area of 5000 square meters are equipped with sheet metal cold processing equipment, 30 sets of welding machine and other special processing machines. We have abundant technical force: a number of top professional talent which have above 15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc. We actively participate in international market competition.
Due to our well grounded, rich project management experience and advanced site construction technology, we obtained good performance and well-known reputation. Welcome all the customers can guide and visit our factory in the future.
