PLG Continuous Plate Dryer
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
Product Description
our service
Our 24hr-online WeChat/WhatsApp: +86-13915098637 Skype: merrymiao37
Company Profile
Changzhou Jiacheng Drying Equipment Co., Ltd is founded in 2015, it is a professional manufacturer engaged in the research, development, production, sales and service of drying equipment, providing a variety of drying machine. The company is located in Changzhou City, Jiangsu Province with convenient transportation.
Our new factory is located in Zhenglu Industrial Park, Changzhou City, Jiangsu Province, China. It's only 3 kilometers from downtown and it tightly close to east-ring elevated road of Changzhou and Hengshanqiao Exit of Shanghai-Nanjing Expressway.
Our company owns a 8000m2 composite comprehensive office building, for the 2 large-scale modern machinery heavy-duty manufacturing workshop which covers an area of 5000 square meters are equipped with sheet metal cold processing equipment, 30 sets of welding machine and other special processing machines. We have abundant technical force: a number of top professional talent which have above 15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc. We actively participate in international market competition.
Due to our well grounded, rich project management experience and advanced site construction technology, we obtained good performance and well-known reputation. Welcome all the customers can guide and visit our factory in the future.
Product Description
Description
PLG series continuous plate dryer is a kind of high efficiency conducting and continuous drying equipment. Its unique structure
and operating principle provide advantages of high heat efficiency, low energy consumption, less occupying area, simple
configuration, easy operation and control as well as good operating environment etc. It is widely used in drying process in the
fields of chemical, pharmaceuticals, agricultural chemicals, foodstuff, fodder, process of agricultural and by-products etc., and
is well received by various industries.
PLG series continuous plate dryer is a kind of high efficiency conducting and continuous drying equipment. Its unique structure
and operating principle provide advantages of high heat efficiency, low energy consumption, less occupying area, simple
configuration, easy operation and control as well as good operating environment etc. It is widely used in drying process in the
fields of chemical, pharmaceuticals, agricultural chemicals, foodstuff, fodder, process of agricultural and by-products etc., and
is well received by various industries.
Principle
Wet materials are fed continuously to the top drying layer in the dryer. They will be turned and stirred continuously by harrows when the harrow's arm rotates, the material flows through the surface of the drying plate along the exponential helical line. On the small drying plate the material will be moved to its exterior edge and drop down to the exterior edge of the large drying plate underneath, and will then be moved inward and drop down from its central hole to the small drying plate on the next layer. Both small and large drying plates are arranged alternately so as materials can go through the whole dryer continuously. The heating media, which could be saturated steam, hot water or thermal oil will be led into hollow drying plates from one end to other end of the dryer. The dried product will drop from the last layer of the drying plate to the bottom layer of the smell body,
and will be moved by harrows to the discharge port. The moisture exhausts from materials and will be removed from the moist discharge port on the top cover, or sucked out by the vacuum pump on the top cover for vacuum-type plate dryer. The dried product discharged from the bottom layer can be packed directly.
Wet materials are fed continuously to the top drying layer in the dryer. They will be turned and stirred continuously by harrows when the harrow's arm rotates, the material flows through the surface of the drying plate along the exponential helical line. On the small drying plate the material will be moved to its exterior edge and drop down to the exterior edge of the large drying plate underneath, and will then be moved inward and drop down from its central hole to the small drying plate on the next layer. Both small and large drying plates are arranged alternately so as materials can go through the whole dryer continuously. The heating media, which could be saturated steam, hot water or thermal oil will be led into hollow drying plates from one end to other end of the dryer. The dried product will drop from the last layer of the drying plate to the bottom layer of the smell body,
and will be moved by harrows to the discharge port. The moisture exhausts from materials and will be removed from the moist discharge port on the top cover, or sucked out by the vacuum pump on the top cover for vacuum-type plate dryer. The dried product discharged from the bottom layer can be packed directly.
Feature
(1) Easy control, wide application
(2) Easy and simple operation
(3) Low energy consumption
(4)Good operation environment, solvent can be recovered and powder discharge meets the requirements of exhaust.
(5) Easy installation and small occupying area.
(1) Easy control, wide application
(2) Easy and simple operation
(3) Low energy consumption
(4)Good operation environment, solvent can be recovered and powder discharge meets the requirements of exhaust.
(5) Easy installation and small occupying area.
Technical feature
1. Drying plate
(1). Designing pressure: general is 0.4MPa, Max. can reach 1.6 Mpa.
(2).Work pressure: general is less then 0.4Mpa, and Max. can reach 1.6 Mpa.
(3).Heating medium: steam, hot water, oil.
2. Material transmission system
(1).headstock revoluton:1~10 rpm, electromagnetism of transducer timing.
(2).harrow arm: There are 2 to 8 pieces arm that be fixed on the headstock on the every layers.
(3). Harrow's blade: Surrounding the harrow's blade, float together with the surface of the plate to keep contact. There're various of types.
(4). Roller: for the products easily agglomerate, or with the requirements of grinding, the heat transfer and drying process might be reinforced by placing roller(s) at the appropriate place(s).
3. Shell
There're three types for option: normal pressure, sealed and vacuum
(1). Normal pressure: -----
(2). Sealed: Cylindrical shell, could bear the interior pressure of 5KPa, the main ducts of the inlet and outlet of heating media might be inside of the shell or outside.
( 3). Vacuum: Cylindrical shell, could bear the exterior pressure of 0.1MPa. The main ducts of inlet and outlet is inside of the shell.
4. Air heater:
Normal for the application of big evaporation capacity to increase drying efficiency.
1. Drying plate
(1). Designing pressure: general is 0.4MPa, Max. can reach 1.6 Mpa.
(2).Work pressure: general is less then 0.4Mpa, and Max. can reach 1.6 Mpa.
(3).Heating medium: steam, hot water, oil.
2. Material transmission system
(1).headstock revoluton:1~10 rpm, electromagnetism of transducer timing.
(2).harrow arm: There are 2 to 8 pieces arm that be fixed on the headstock on the every layers.
(3). Harrow's blade: Surrounding the harrow's blade, float together with the surface of the plate to keep contact. There're various of types.
(4). Roller: for the products easily agglomerate, or with the requirements of grinding, the heat transfer and drying process might be reinforced by placing roller(s) at the appropriate place(s).
3. Shell
There're three types for option: normal pressure, sealed and vacuum
(1). Normal pressure: -----
(2). Sealed: Cylindrical shell, could bear the interior pressure of 5KPa, the main ducts of the inlet and outlet of heating media might be inside of the shell or outside.
( 3). Vacuum: Cylindrical shell, could bear the exterior pressure of 0.1MPa. The main ducts of inlet and outlet is inside of the shell.
4. Air heater:
Normal for the application of big evaporation capacity to increase drying efficiency.
Specification
item | value |
Type | DRYING OVEN |
Application | Medicine Processing, Chemicals Processing, Food Processing |
Condition | New |
Place of Origin | China |
Voltage | 220v/380v |
Power | 1.1kw-15kw |
Dimension(L*W*H) | Based on different model |
Certification | CE |
Key Selling Points | Energy saving |
Warranty | 1 Year |
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service | |
Weight (KG) | Based on different model |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Applicable Industries | Manufacturing Plant, Food & Beverage Factory, Farms, Retail, Food Shop, Food & Beverage Shops, Other, Pharmaceutical Industry |
Local Service Location | None |
Showroom Location | None |
Marketing Type | New Product 2020 |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Warranty of core components | 1 Year |
Core Components | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine |
Evaporation Capacity(kg/h) | Pharmaceutical Industry |
Heating Method | heating source can be customized according to customer requirements |
Material | SUS304, SUS316, SUS316L |
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2016,sell to Southeast Asia(7.00%),Eastern Europe(5.00%),Northern Europe(5.00%),Oceania(3.00%),Southern Europe(3.00%),South Asia(3.00%),Africa(2.00%),Domestic Market(2.00%),Central America(2.00%),Western Europe(2.00%),North America(2.00%),Mid East(2.00%),South America(1.00%),Eastern Asia(1.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Spray Dryer,Paddle Dryer,Spin Dryer,Fluid Bed Dryer,Belt Dryer
4. why should you buy from us not from other suppliers?
Changzhou Jiacheng has abundant technical force: a number of top professional talent which have above15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Jiangsu, China, start from 2016,sell to Southeast Asia(7.00%),Eastern Europe(5.00%),Northern Europe(5.00%),Oceania(3.00%),Southern Europe(3.00%),South Asia(3.00%),Africa(2.00%),Domestic Market(2.00%),Central America(2.00%),Western Europe(2.00%),North America(2.00%),Mid East(2.00%),South America(1.00%),Eastern Asia(1.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Spray Dryer,Paddle Dryer,Spin Dryer,Fluid Bed Dryer,Belt Dryer
4. why should you buy from us not from other suppliers?
Changzhou Jiacheng has abundant technical force: a number of top professional talent which have above15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
All the machine for the spare parts are packed in 20GP, 40GP, 40HQ. Shipping to Shanghai seaport or CIF destination port.
Our Advantages
1.Engineers available to service machinery overseas (All counties).
2. Overseas service center available (some countries).
3. Overseas third-party support available (some countries).
4. Our engineer have above 15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc.
5. We have rich project management experience and advanced site construction technology, we obtained good performance and well-known reputation.
6. We can show you the best price and high-quality machine.
7. We can show you the best price for our old customers, all new customers we will give 5% discount for the first time.
2. Overseas service center available (some countries).
3. Overseas third-party support available (some countries).
4. Our engineer have above 15 years professional experience in drying industry engaged in design, mechanical drawing, electrical automation edit etc.
5. We have rich project management experience and advanced site construction technology, we obtained good performance and well-known reputation.
6. We can show you the best price and high-quality machine.
7. We can show you the best price for our old customers, all new customers we will give 5% discount for the first time.
