LPG 5 Spray Dryer Milk Spray Dryer Mini Spray Dryer Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
KODI LPG-5 Lab Small Spray Drying Machine Powder Spray Dryer
-
Food Powder Lab Mini Spray Dryer
-
KODI Lab LPG 5 Spray Dryer Milk Powder Pilot Spray Dryer
-
KODI Industrial Small Scale Spray Drying Machine Powder Spray Drying Machine
-
KODI Industrial Pilot High Speed Centrifugal Lab Spray Drying Machine
-
KODI Industrial Small Scale Arabic Gum Spray Drying Machine Powder Spray Dryer
Product Description
Product Description
Lab Spray Dryer Description
LPG Pilot spray dryer/ Lab Spray Dryer/ laboratory spray dryer/ lab spray drier/ lab scale spray dryer is a wide applied process in liquid process shaping and drying industry. Particularly mini spray dryer is suitable for producing powder, granule or block solid product from solution, emulsion, suspending liquid and pumped paste liquid. Therefore when the distribution of granule size, final moisture, bulk density, granule shape of finished product must be conformed to accuracy standard, the spray drying is an ideal process.
Lab Spray Dryer Application
LPG lab spray dryer / pilot spray dryer / pilot spray drying machine is widely used in foodstuff, pharmaceutical and chemical industry, such as egg powder, amino acid product, protein, blood, food flavor, food ingredients, pectin, carrageenan, spirulina, herbal extraction, pigment, cocoa, mushroom, PAC, malt dextrin, collagen, juice, yeast, Coffee, Creamer, coconut, milk, gelatin, gum and acacia etc.
Pilot Spray Dryer Working Principle
After filtering and heating, the hot fresh air enter into the air distributor at the top of drying chamber, distributed in spiral
way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.
way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.



Specification
Evaporation | 3~5Kg/h | Dia/Height | 1.0M/2.2M |
Operation temperature | Inlet 180℃ Outlet 90℃ | Atomizer Dia 50mm | Compressed air driving |
Power | Drive:0.75KW | Water consumption | 0.1m3/h |
Heater:12-15KW | |||
Type | Open circle | Feeder | peristaltic pump |
Air contact | Co-current | Heater | Electric heater |
Collection | Cyclone | Atomizer | Centrifugal atomizer |
Overall size | 1.68x1.5x2.1 | Weight | About 500Kg |
Packing | Plywood box | Power | 3Ph, 220-415V, 50/60Hz |
Parameters
No. | Item | Model | Qty | Material | Notes | |||||
Feeding system | ||||||||||
1 | peristaltic pump | BT-100 | 1set | Sanitary | 0.3Kw | |||||
2 | Feeding pipe | 1set | SUS304 | |||||||
Circulation system | ||||||||||
1 | Suction blower | 9-19 | 1set | SUS304 | 0.75KW | |||||
2 | Air valve | 1set | SUS304 | |||||||
3 | Hot air pipe | 1set | SUS304 | |||||||
4 | Air out pipe | 1set | SUS304 | |||||||
5 | Pipe fittings | 1set | SUS304 | |||||||
Air system | ||||||||||
1 | Air filter | 1set | SUS304 | Initial and middle | ||||||
2 | Air heater | 12Kw | 1set | SUS304 | ||||||
3 | Pipe fitting | 1set | SUS304 | |||||||
4 | Hot air pipe | 1set | SUS304 | Insulation | ||||||
Main machine | ||||||||||
1 | Drying chamber | D1000H2200 | 1set | SUS304 | ||||||
2 | Air distributor | 1set | SUS304 | |||||||
3 | Air cover | 1set | SUS304 | |||||||
4 | Atomizer | LPG5/Dia 50mm | 1set | SUS304 | Air driven | |||||
5 | Light | 100W | 1set | |||||||
6 | Manhole | 1set | SUS304 | |||||||
7 | Insulation | Glass fiber | ||||||||
8 | Hammer | SK40 | 2sets | Aluminum | ||||||
Powder collection system | ||||||||||
1 | Cyclone | XF170 | 1set | SUS304 | ||||||
2 | Discharge valve | 1set | SUS304 | |||||||
3 | Product jar | 1set | SUS304 | |||||||
4 | Air pipe | Quick opening | 1set | SUS304 | ||||||
Control system | ||||||||||
1 | Control box | 1set | SUS304 | |||||||
2 | PLC | SIEMENS | 1set | |||||||
3 | Touch screen | SIEMENS | 1set | |||||||
4 | Contactor | SIEMENS | 1set | |||||||
