Product Description
Product Overview
What can our Fluid Bed produce ?
Medicine granulation and coating
Granulation: tablet granules, granules for granules and capsules.
Coating: granules, protective layer of pills, color preparation, slow release, film, enteric coating.
Food Granulation and Coating
Sugar, coffee, cocoa powder, butter, powdered fruit juice, amino acids, condiments, puffed food.
Pesticide, Pigment Pigment and Dye Granulation
Drying of Powdery, Granular and Block Materials
Advanced Advantages
1). Mixing - granulation - drying - in one machine (one step granulation).
2). Adopting double chamber filtering bags system, removing dust completely. Using antistatic filter material, the equipment is safe to operate.
3). The binder nebulizer adopts multi-fluid spray gun, which has uniform spray particles, the content of powder is very low, greatly improves the qualified rate of finished products.
4). Can choose two bars explosion-proof design
5).The equipment has no dead angle, the loading and unloading material is light, fast and clean.
5) Designed, manufactured and laid out up to pharmacy industry standard.
6)Design&Manufactured in accordance with JB20014-2004
Production on Site
General Layout
Production on Site
PRODUCT SPECIFICATIONS
Model | 5 | 30 | 60 | 120 | 200 | 300 | 500 | ||||||
Capacity(kg/b) | 5 | 30 | 60 | 120 | 200 | 300 | 500 | ||||||
Material Yield Rate% | >/=99% | ||||||||||||
Qualified Rate | </=85% | ||||||||||||
Container Volume L | 22 | 100 | 220 | 420 | 670 | 1000 | 1500 | ||||||
Diameter mm | 500 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | ||||||
Power Fan KW | 3 | 7.5 | 11 | 18.5 | 22 | 30 | 45 | ||||||
Liquid Feed Power KW | 0.37 fluid bed dryer granulator | ||||||||||||
Pressure Steam | 0.4~0.6 MPa | ||||||||||||
Consumption Steam | 18 | 60 | 120 | 140 | 180 | 310 | 400 | ||||||
Compressed Air | 0.4~0.6 MPa | ||||||||||||
Consumption Air | 0.3 | 0.9 | 0.9 | 0.9 | 1.1 | 1.1 | 1.1 | ||||||
Working Temperature C | Room Temperature to 120C adjustable | ||||||||||||
Noisy dB | Installed Separated with Fan </=75 | ||||||||||||
Successful Project
FL300 in EU
FLG120 in Phillipines
FG60 in Mexico
PRODUCT CONFIGURATION
Main Tower
Air Handle System
Two Fluid Spray System
Welcome to SINOPED ! Fluid bed dryer granulator
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (Sinoped) is a professional manufacturer and supplier of pharmaceutical machinery in China. It integrates development, manufacture, sales, after-sale services as a whole, being a professional supplier for dryer granulator, mixer, coater. Solid preparation machine, such as filling machine , capsule machine, tablet machine, packing machine and clean room turnkey project for pharmacy factories. All of machinery fully come up to G M P requirement.
Testified by the experience of long-term users, our products have very high stability and reliability, which have been sold to more than 20 regions, cities, and provinces around China and some foreign countries like Asian, European, American. Sinoped have established long-term business relations with many customers and some of them already cooperate as our agent in their countries.
For many years, we`re stick to the principle of "Customers First" taken the initiative to manage customers` demands, to develop and research high-quality pharmaceutical equipment, set up a perfect after-sale service system, and brought up the concept of" Star service" The pharmaceutical equipment is worth of your trust, Let`s join hands to co-develop a brilliant future in the 21st century full of opportunities! Brand from concentration——Our pursuit is to product the best cost-effective machines in China. In this 21-century full of opportunities and challenges, Sinoped will provide new equipment and more pragmatic spirit of innovation, cooperate with you and create brilliance!
