Made in China Taian Common Rail Injector Test Bench CRS-205C for Common Rail Diesel Injector Tester CR EPS205 NTS205 DTS205
- T/T Credit Card
You May Like
-
Common Rail EUI EUP Tester Unit Pump Test Bench With Cam Box COM-EUI/EUP
-
COM-1800S EUI-EUP Uint Pump Tester Euieup Test Bench
-
High-quality 12PSB Fuel Pump Calibration Test Bench
-
Test Machine COM-1800S Common Rail EUI/EUP Test Bench CR927S With Computer Optional Add ISX15,QSK19/23/60
-
China Made Machine Mechanical Pump Test Bench COM-EMC Injection Pump Inline Pump Tester Diesel China EPS815 Optional Add EUI/EUP
-
Hight Quality Common Rail Test Bench CRS-825C With IMA Code,QR Code Creating Function for Injector and Pump Test Machine
Product Description
CRS-205C Common Rail Injector Tester
it can test common rail injector of B-osch,D-enso,D-elphi,S-iemens
and piezo injector!
Can provide customization,
Color optional
The device fully simulates the principle of the injection system of the high pressure common rail engine, and the main drive adopts the servo control technology.
Pump speed, injection pulse width and rail pressure are all controlled by industrial computer by real time, oil quantity is displayed by flow meter sensor, compare debug data automatically.
10.4 LCD touch screen display,it contains more than 1000 kinds of injectors data by computer,search, print(optional). Adjusted by drive signal, high precision, steady performance.
>>>CHARACTERISTIC
1. Main drive adopts the servo control technology
2. Controlled by industrial computer in real time.
3. Oil quantity is measured by flow meter sensor and displayed on 10.4, LCD .
4. Rail pressure can be tested in real time, it adopts closed-loop control system,
and it contains the high-pressure protection function.
5. Data can be searched, saved and printed (optional).
6. Pulse width of the injector drive signal can be adjusted.
7. Protection function of short-circuit.
8. Plexiglass protective cover, easy and safe operation.
9. Using 220V AC single-phase power supply.
>>>FUNCTION
1.test brand:D-enso B-osch D-elphi,S-iemens common rail
2.test the seal of high-pressure common rail injector.
3.test the max. oil quantity of high-pressure common rail injector.
4.test the backflow oil quantity of high-pressure common rail injector.
5.test the cranking oil quantity of high-pressure common rail injector.
6.test the pre-injection of high-pressure common rail injector.
7.test the average oil quantity of high-pressure common rail injector.
8.Data can be searched, saved and printed (optional).
9.also can test pizeo injector
>>>TECHNICAL PARAMETERS
|
Motor power |
2.6KW |
|
Input power |
220V/1PH |
|
Operating system |
LINUX or WIN7 |
|
Cooling system |
AT0608T |
|
Rail pressure |
0-2500 bar |
|
Pulse width |
0.1-3ms |
|
Test oil filter precision |
5μ |
|
Rotation speed |
0-3000RPM |
|
Oil tank capacity |
15L |
|
Overall dimension(MM) |
800×810×820 |
|
Weight |
170KG |
