12V 24V CTF-010 100NM 230v quarter turn electric actuator
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
24v electric actuator on-off type CTF-005 50NM 12v 24v actuator for ball valve
-
motorized valve dn40 BSP NPT dn25 dn32 dn50 CTF-001 ss304 2 way stainless steel ball valve
-
1 \"electric ball valve full bore BSP NPT CTF-001 10nm SS304 dn25 1\" stainless steel 304 electric ball valve
-
2way 12v motorized valve BSP NPT CTF-001 dn50 dn15 ss304 dn32 mini motorized ball valve
-
dn32 dn40 UPVC electric valves 220V CTF-002 20NM automatic electric flow control valves
-
220v UPVC motorized valve BSP NPT CTF-002 20NM DN32 dn40 UPVC motorized valve with manual override
Product Description
1. The housing be made of die-cast aluminum, with metal texture, compact structure, beautiful appearance, light and small size, shockproof and crash-proof
2. Adopts the machined gear drive mechanism, large output torque, stable operation, low noise
3. Electric and manual override design, with a transparent window, can know the valve open/close situation at a glance
4. Actuator with ISO5211 connection with the different type valve directly connected, high transmission efficiency,the first choice for smart meter
5. Double sealing structure,IP65 protection class
6. Can use active and passive signal output
1. Pure water and raw water pipeline systems
2. Drainage and sewage, salt water and sea water pipeline systems
3. Acid-base and chemical solution systems and so on
|
Model
|
Voltage
|
Motor power
|
Working current
|
Output torque
|
Working pressure
|
Environment temperature
|
Open/close time
|
| CTF-010 | AC220v | 25W |
1000mA |
100NM |
0-1.6MPa |
0-60℃ |
18-25s |
|
Valve size
|
Ball valve(DN15-65),butterfly valve(DN50-DN125)
|
||||||
| Valve material | UPVC,CPVC,cast steel,cast iron,stainless steel | ||||||
