Mixer for Chocolate Chocolate Storage Tank Chocolate Mixing Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Chocolate Mixer Machine Hot Chocolate Machine Mixer
-
Made in China Fully Automatic Industry 800KG/H Garlic Slicing Production Line
-
Made in China Fully Automatic Industry 800KG/H Complete Garlic Production Line
-
Made in China Fully Automatic Industry 800KG/H Packaging Production Line for Peeled Garlic
-
Fully Automatic Industry 800KG/H Garlic Peeler Machine Processing Production Line
-
Made in China Fully Automatic Industry 800KG/H Garlic Peeling and Packing Production Line
Product Description
Chocolate processing equipment
The chocolate mixer is mainly composed of inner and outer cylinders, agitator, power transmission, heater, circulating water pump and other auxiliary components.There is a heat transfer interlayer between the inner and outer cylinders. The upper part of the cylinder has an overflow pipe and the lower part has a water inlet pipe. The interlayer uses water as the heat carrier, and uses self-circulating hot water to heat up, which can keep the slurry in the container constant temperature.The center of the cylinder is equipped with a hammer stirrer, which can stir the materials uniformly to increase the heat exchange rate of the materials to achieve uniform mixing and consistent temperature.The connection between the agitator shaft and the reducer adopts a direct plug-in installation structure, which is convenient for maintenance.The mixer is equipped with a self-circulating water pump to ensure consistent material temperature.The right side of the cylinder head is equipped with an automatic safety shutdown device for opening the cover. When the cylinder head is opened, the mixing motor will automatically stop. When the mixing motor needs to be turned on, the cylinder cover must be covered to start.
power | 7.5 KW |
Stirrer speed | 38 r/min |
Stirrer steering | Counterclockwise |
heating method | Steam heating |
steam pressure | 0.1-0.3MPa |
Body weight | 13000 Kg |
Dimensions | 2760×630×900 |
SHANDONG XINDAXIN MACHINERY CO., LTD is a professional global supplier of food industry equipment. Company is focused on R&Dmanufacturing and sales of food industry equipment including processing line for snacks, frozen French fries, potato chips,meat food , cake baking ,vegetable processing,corn processing and so on. We provide a compete production line to our customers,corn processing. Company’s products have been certified by CE and ISO9000(1)-2000 international quality management system certification, and in accordance with the QS standard food enterprise. After many years of efforts and innovation, “TCA”brand food equipment has been exported to Russia,Canada,Australia, USA, Britain, France and other 80 countries, enjoy a high reputation in
the same industry.
the same industry.
