Gfrp Rebar, Fiberglass Reinforced Plastic FRP Rebar
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Support Bolt Glass Fiber Reinforced Tunnel Support FRP Rebar
-
Factory Supply Gfrp Fiberglass Rebar Basalt Fiber Rebar Carbon Fiber Rebar
-
10mm FRP Anchor Plate and Fiberglass Nut for FRP Rebar Basalt Fiber Rebar
-
Gfrp Fiberglass Bar Epoxy Composite Fiberglass Rebar Glass Fiber Rebar
-
18mm 20mm Bfrp Gfrp Fiberglass Reinforced Rebar
-
Gfrp Fiberglass Bar Epoxy Composite Fiberglass Rebar Glass Fiber Rebar
Product Description
Product Description
Fiberglass Rebar is a new kind of composite material, which is glass fiber, basalt fiber, carbon fiber as a reinforcement
material, combines with epoxy (resin) and curing agent, then through the Molding process.
Advantage:
1. High corrosion resistance
-The fiberglass used by the rebar are durable materials, and they are molded through the composite process. The life span
is up to 100 years. They can be used as permanent support materials.
2. A high tensile strength
-The load is approximately double that of a steel bar with the same diameter
3. Low weight
-The weight is only 1/4 that of a steel bar with the same diameter, therefore, the labor intensity is greatly reduced, and the
transportation cost is reduced at the same time
4. Anti-static
-It has no electrical conductivity, and no sparks will be produced when being cut, it's particularly suitable for high gas zones;
5. Non-flammable
-It's non-flammable and has high thermal isolation;
6. Cuttability
-It avoids damages to cutter heads and does not delay excavation
7. Save cost
-Use this material as reinforcing bars for road and bridge, could reduce secondary repair cost.
Specification
diameter (mm) | Weight per meter(kg) | Meters per ton | tensile strength Mpa |
8 | 0.1 | 10000 | ≥750 |
10 | 0.15 | 6666 | ≥750 |
12 | 0.2 | 4762 | ≥750 |
14 | 0.28 | 3572 | ≥750 |
16 | 0.32 | 3125 | ≥600 |
18 | 0.43 | 2326 | ≥600 |
20 | 0.55 | 1819 | ≥600 |
22 | 0.61 | 1640 | ≥600 |
25 | 0.95 | 1053 | ≥600 |
28 | 1.15 | 870 | ≥600 |
30 | 1.36 | 735 | ≥600 |
32 | 1.51 | 663 | ≥600 |
34 | 1.71 | 584 | ≥600 |
36 | 1.91 | 524 | ≥600 |
Appearance:uniform texture,no bubbles,cracks and other defects affecting strength
Length deviation:±10mm , Diameter deviation:±1,mm
Strainghtening of rod body:≤3mm/m , Ultimate strain:≥1.2 , elastic modulus:≥40Gpa
Details Images
Product Name | Glass fiber reinforced rebar |
Material | Fiberglass plastic, expoy resin, curing agent |
Product features | Light weight, intensile strength, corrosion resistance, non-magnetic, easy to cut, no electricity, no heat conduction and no rust ect. |
Product specifications | Diameter: φ8—φ40 Length: Customized (Normal: 1.4m-2,6m) Shape: Customized |
Product parameters | Tensile strength ≥ 600-1000MpaShear strength ≥ 110Mpa Elastic modulus ≥ 40Gpa Density 1.9 g/cm3 ~ 2.2 g/cm3 |
Certification | ISO9001, CE |
Colors | Customized (Normal:Black,Yellow) |
Sample | Free (Not bear the freight cost) |
Packaging | Bulled on the pallet with stretch film |
Company Profile
Hengshui Aoliande Trade Co., Ltd. is professional manufacturer of FRP Pipe, FRP storage tank, FRP cooling tower, FRP molded products, FRP pultruded products and relative FRP production machines & technology. Through the continuous development and introduction of professional technology, our company rely on advanced technology, exquisite craftsmanship, reliable quality and perfect service, passed ISO9001, ISO14001, OHSAS18001 certification, our annual sales of glass fiber reinforced plastic series products achieved 20,000 tons.
Major products:
FRP vessel and chemical equipment in sets; FRP high, medium & low pressure pipe FRP septic tank FRP molded & pultruded products
Electrolytic cell，S/F, F/F oil storage tank，F(xiàn)RP duce pipe FRP absorber FRP Packing tower Tailgas absorber FRP scrubber duct pipe etc....
