Home > Products > Fiber optic gyrocompass > FG-980S Inertial Navigation System
FG-980S Inertial Navigation System
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
INEM-100 Fiber Optic Gyro Compass System Attitude reference system and motion sensor
-
FG-700B Fiber Optic Gyrocompass And Attitude Reference System
-
PTK-20 Fiber Optic Gyro Compass System Inertial Measuring System for Pipeline Surveying
-
FG-800A Model Fog Attitude And Heading Reference
-
F70MC single-axis medium accuracy military standard fiber optic gyroscope
-
F70HA 0.05 degree/hr single-axis medium accuracy military standard fiber optic gyroscope
Product Description
FG-980S Inertial Navigation System
Alignment Time | GC:5min Fast:1.5min | ||
Accuracy | Position | Inertial:0.8nmile/h Integrated:30m | |
Velocity | Inertial:0.8m/s Integrated:0.5m/s | ||
Attitude | Inertial:0.05° Integrated:0.04° | ||
Heading | Inertial:0.07° Integrated:0.06° | ||
Dynamic Range | Angular Rate | ±400°/s | |
Acceleration | ±15g | ||
Operation Requirement | Temperature | Work:－45～＋70℃ Storage:－55～＋85℃ | |
Shock | Half-sinusoid:15g,11ms | ||
Vibration | 0.04g2/Hz | ||
MTBF | 50000h | ||
Power Supply/Consumption | 28VDC/30W | ||
Interface | MIL-STD-1553B ARINC-429 RS-422 | ||
Dimension | Navigation unit:238mm×188mm×190mm Max size:254mm×188mm×190mm | ||
Weight | 7.1kg(excluding receiving antenna) | ||
