Marine Electronics Maritime Navigation Communication SAMYUNG CE RMRS SFAX-500 Ship Boat Weather Fax Weather Facsimile Receiver

• Easy weather chart distinction by 10 inch wide printer output

• Simple setting & operation by 5.6 inch full screen color LCD display

• 4 receiving mode (automatic, manual, forced, timer programming)

• Automatic search for optimal receiving channel

• Select a station depending on GPS signal.

• Clear screen by anti-noise device.

• Receive standard weather information from WMO (World Meteorological Organization)

• Select Black, Yellow and Black, Green and Black in screen.

• Auto tune to optimize receiving quality.

• Connect to the best station by setting automatic receive channel.

• Recording system : Solid state thermal head

• Recording paper : thermo sensitive recording paper

• Effective recording width : 256mm (10")

• IOC (Index of cooperation) : 576 or 288

• Scanning speed : 60, 90, 120, 240 RPM

• Scanner resolution : 8 dots/mm

• Scanning line density : approx, 7 lines/mm, 3.5 lines/mm

• Phase matching : automatic and manual

• Halftone recording : 16 steps by dither pattern

• Negatice/positive recording : manual

• External receiver connect : 0dBm@ 600Ω

• Operation mode : automatic, manual, forced, timer program

• Timer program channel : 30 channels

• Setup data list recording : receiving frequency, tiner program channel

• Setup data storing : Flash memory

• Self test function : recording and print test

• Automatic time correction : input via GPS data

• Image data output : display received images on LCD (5.6"), save to SD card

• Receiving system : up-conversion, double super heterodyne, phase locked

• Frequency type : F3C

• Frequency range : 500KHz ~ 25MHz

• Frequency selection : automatic and manual

• Frequency memory 100 channels

• Sensitivity : 2uv(+6dBμ)or less@20dB S/N(output :-5dBm)

• Image rejection ratio : more than 60dB

• Ambient temperature operation : -15℃ to +55℃

• Ambient humidity : 93% (40℃) or less recirding is 80% or less

• Power supply : DC24 10% to +30%, 70VA or less
