A solution to support smooth transition from paper-based navigation to electronic navigation

IHO/S-57 Edition 3 vector chart (IHO S-63 data protection scheme)

·    Admiralty Vector Chart Service by UKHO

·    C-MAP CAES

·    Jeppesen Primar ECDIS Service

 ARCS raster chart

 C-MAP Professional+*

 Compatibility with Admiralty Information Overlay (AIO) for further navigation safety

Additional AIO layer includes all Admiralty Temporary and Preliminary Notices to Mariners as well as additional ENC Preliminary Notices to Mariners, i.e.,

reported navigational hazards that have been incorporated into a paper chart, but have yet to be included in ENCs.
The service is free of charge as part of Admiralty Vector Chart Service (AVCS) by UKHO.

Streamlined integration into the onboard navigation system; perfectly suited for ECDIS retrofitting projects

 2 LAN ports and 4 serial ports are available to facilitate smooth integration into a bridge network as well as interface with onboard navigation sensors

 Flexibility in installation; supporting both table-top mounting* as well as flush-mounting to match the space availability in the wheelhouse

Suitable for both primary and back-up ECDIS

Dual configuration of the FMD-3100 supports the vessel to go paperless.
For those who have already installed the FMD-3200/FMD-3300 onboard the vessel, the FMD-3100 can be used as a cost-effective back-up arrangement for the FMD-3200/FMD-3300 ECDIS.

Instantaneous chart redraw delivered by FURUNO’s advanced chart drawing engine, making redraw latency a thing of the past

Easily interfaces with existing FAR-2xx7 series Radar for:

 Radar overlay

Route and waypoint

Target track info

 User Charts

exchange via Ethernet

*Software update on FAR-21x7/FAR-28x7 series might be necessary depending on the program number.
*for Radar overlay with analog Radar such as FAR-2xx5 series, the optional RCB-002 Radar Connection Box is required.

 Complies with the following IMO and IEC regulations:

 IMO A.694 (17)

IMO MSC.191 (79)

IMO MSC.232 (82)

IMO MSC.302 (87)

IEC 60945 Ed. 4

IEC 61162-1 Ed. 5

 IEC 61162-2 Ed. 1

 IEC 61162-450 Ed. 1 AMD1

IEC 61174 Ed. 4

IEC 62288 Ed .2
