Product Description
Please contact me before purchasing for the shipment and price and detailed configuraiton.
If you want to make bulk purchase or be our agent, please contact with us.
DS2008, navigation echo sounder with a 10.4 inch, high resolution graphic LCD, continuously dispaly echo graphics on the LCD along with complete navigational details.
External connectors are provided for printer, and NMEA in/output.
DS2008 contains history memory that stores depth, time and other available navigation data continuously for the preceding 20 hours.
Dual channels echo sounder display DS2008S and DS2008H can display depth at the FORE and AFT positions simultaneously.
Features
10.4 inch color TFT LCD
50 kHz / 200 kHz transducer
20 hours history data record
NMEA0183 Depth data output
Printer interface forDPU-414 printer to print out date/time/location/depth information
Compatible with most echo sounder transducer in the market
(inquire us more for replacment project)
| ITEM | SPECIFICATIONS | ITEM | SPECIFICATIONS |
| Display | 10.4” color LCD with adjustable backlight | Auto Range | Yes |
| Pixel Number | 640×480 | Alarm | Shallow water, Power drop |
| Power Supply | DC24V (18~33V) | Power Alarm | Power lost alarm |
| Dimension | 264(H)×270(W)×93(D)mm | Alarm Media | Buzzer, Flashing |
| Model | DS2008: 200kHz only × 1 channel | Time Scale | 30s interval time bar on LCD |
| DS2008: 50kHz only × 1 channel | Picture Speed | 6 steps plus freeze | |
| DS2008H: 200kHz × 2 channels | NMEA Outputs | NMEA0183 (DPT) | |
| DS2008S: 50&200kHz, 2 channels | NMEA Input | GPS Position (GGA) | |
| Power Output | DS2008 & DS2008S: 500W | Echo color | 7 colors |
| DS2008H: 300W | Language | English, Chinese | |
| Mounting Dimensions | 261 × 247 mm | Protection | Display IP23(IEC60945) |
| Mounting | Desk/Ceiling/Flush | ||
| Depth Range | 0.4m to 800m | Options | Depth repeater IR261 |
| Accuracy | Error less ±1.0% of range | Printer DPU-414 | |
| History Storing | 20 hours history data | Classification | Made to IMO performance standard |
