TYA Series Wide Application Engine Lubricating Oil Purifier Machine Minimizing Fluid Oxidation, Maintaining Lubricity Properties
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Vacuum Oil Purification System for Turbine and Hydraulic System to to Reduce Moisture, Gas and Particulate
-
PL-100 Paper Filtering Used Diesel Oil Plate Press Filtering Machine
-
TYS-10 Powerful Motor and Vacuum Pump for Oil Filtration Machine
-
TYS-A-10 Waste Restaurant Oil Purifying and Decolorization Machine
-
TYD-150 304 Stainless Steel Edible Oil and Water Separation Machine
-
Ready to Ship TYR-100 Used Red Diesel Oil Filtering and Purifying Machine
Product Description
Product Description
TYA Series Wide application Engine Lubricating Oil Purifier Machine minimizing fluid oxidation, maintaining lubricity properties
(TY Series)
Application:
TYA Series oil filtering machine is applied for on-line oil filtration in electric power, metallurgical, chemical engineering industries. It is good at emulsion breaking, dehydration and removing moisture gas impurities, soap, gelatin, acid, pigment and metal particulates in emulsified turbine LUBE oil and low-viscosity lubricating oil as well as turbine oil used in other machinery and electric power equipment, and improve the oil quality to ensure a normal work of the generator sets adjustment and lubrication system.
Features:
1. it is strong ability of dehydration and breaking emulsion, that is easy to separate the great moisture and tiny moisture out of the used oil. Because of the special break emulsion device (water separator), the emulsified oil could be treat and become transparent. 2. It is strong ability of removing impurities, that is the big area and deep-seated accurate filtration material can eliminate the tiny particles from used oil that could replace oil system clean device, make great polluted oil system recovered and meet “the operating turbine oil pollution control standard” 3. It is strong ability of automatic, safe and reliable operation. This model is used float ball level automatic control device that realizes auto working completely without manual labour, leads to a simple and stable operation. 4. Thus, TY series is specially fit for applying to filter turbine oil, hydraulic oil and the low viscosity oil that contains lots of water or tiny particles which need to be precisely processed. 1.It adopts the coalescence and separation technique and 3D-Evaporation technical and thin film evaporation technique, and it has strong ability to break emulsion and remove water from the oil. 2.Optimized electric heating system with automatic constant temperature controller ensures the oil temperature to be even and stable. 3.Precise multi-stage filtration system helps remove different kinds of impurities with high quality filter element of better ability of containing pollutants and long service life 4.Advanced infrared oil level control system and pressure protection device make operation simple and safe. 5.It can purify any kinds of turbine oil used in steam turbine and water turbine online and onsite. 6.Air cooling system helps cool down air and gases from the flash distillation column so as to extend the service life of vacuum pump, avoiding the inconvenience of water cooling. 7.The machine can also be installed with digital flow meter and timer to calculate and record the volume of output oil and working hours (it’s optional). 8.Aluminum electric control cabinet has the merits of heat conducting and anti-explosion 9. Adopts interlocked protective system, which connected oil pump, heater, and oil level sensor, avoiding blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically. 10. High quality and low noise oil pump 11. Hi-automatization operation, convenience, reliable, and safety Special features 1. The plant is delivered ready for operation. 2. Continuously clean the oil 3. On-line water content measuring device (optional) 4. All oil treatment plants, type TY are equipped with an automatic Anti-Foam Control System. 5. The plant is equipped with built-in control and safety devices, which provides for a maximum operating security. 6. Minimised power consumption through optimised degassing (excellent efficiency factor). 7. Standardized filter housing for 1 micron , 5 micron, 20 micron and 80 micron filter cartridges. 8. Automatic supervision of the degree of contamination of the fine filter cartridges 9. All parts of the machine are stainless steel and food grade material 10. All plants are PLC controlled (optional)
To meet customers’ special needs, we develops
TY semi-automatic turbine oil purifier,
TY-A automatic turbine oil purifier with PLC
TY-Ex Ex anti-explosion turbine oil purifier for different requirements and working conditions.
TY-W Enclosed type turbine oil purifier which can prevent rain, sun, dust
TY-M Mobile outdoor type turbine oil purifier which can move and operate on-site
Working Principle
While the oil purifier is working, the oil will flows into the heater by the pressure of inner and external. After heating, the oil goes into the 1st-stage filter to remove big particles and then reaches 2nd-stage filter (that is water separator) which adopts strengthen hydrophilic oleophobic technique to change the mutual acting force from oil and water surface, make the tiny water droplets in oil move fast and coalesce into big water droplets that would be separated out and subsided in the water storage tank. Meanwhile the oil enters into the vacuum tank and pass by sprinkler which make the oil sprayed and formed big aerating area and long aerating time, that could finally separate gas from oil. The mixed gas that contains steamed water and gas will go across the condenser and form liquid, which would be discharged by vacuum pump. The oil whose water was removed will be pumped into 3ird-stage filter to eliminate tiny impurities and precisely purified by fine filter, finally get clean oil out.
Technical Parameters
Parameter | Unit | TYA -10 | TYA -20 | TYA -30 | TYA -50 | TYA -100 | TYA -200 | TYA -300 | ||||||
Flow rate | L/min | 10 | 20 | 30 | 50 | 100 | 200 | 300 | ||||||
Vacuum degree | Mpa | -0.06～-0.095 | ||||||||||||
Working pressure | Mpa | ≤0.5 | ||||||||||||
Working temperature | ℃ | ≤40~60 (no more than 55℃ for purifying turbine oil.) | ||||||||||||
Power Supply | V/Hz | 380/50/3P (Customized) | ||||||||||||
Heating power | kW | 15 | 18 | 24 | 30 | 60 | 81 | 90 | ||||||
Total power | kW | 17 | 20 | 26 | 32 | 64 | 86 | 100 | ||||||
Inlet (outlet) dimension | mm | Φ32 | Φ32 | Φ32 | Φ42 | Φ42 | Φ60 | Φ76 | ||||||
Weight | kg | 400 | 480 | 600 | 700 | 800 | 1100 | 1350 | ||||||
Size | L, mm | 1300 | 1300 | 1400 | 1400 | 1500 | 1850 | 2100 | ||||||
W, mm | 1000 | 1050 | 1100 | 1150 | 1100 | 1300 | 1400 | |||||||
H, mm | 1600 | 1700 | 1800 | 1850 | 1850 | 1900 | 2000 | |||||||
Item | Guarantee oil index after treated |
Moisture content | ≤50 PPM |
Demulsification value | New oil≤15min,running oil≤30min |
Impurity size | ≤1 micron |
Gas content | ≤0.1% |
Clean degree | ≤4 Grade (NAS1638) |
Detailed Images
We also have other types of oil purifier machines and test equipment, if you need any one related equipment, pls tell me to quote them together. You can send me inquiry here or contact me at +8613983286435 (Mob/Whats App) or sales10( at ). I will response the soonest within 24 hours.
Recommend Products
Packing&Shipping
Packing: standard export wooden case per set.
Delivery method: the oil purifier machines are usually delivered by sea, but other method is available if necessary.
Delivery method: the oil purifier machines are usually delivered by sea, but other method is available if necessary.
Company Introduction
Located at Chongqing city--a southwest electromechanical manufacturing center as well as national municipality, Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.
TOP Oil Purifiers are widespread in the fields of electric power, petrifaction, mineral, shipbuilding, steel construction, bridge, automobile and railway, playing a great role in reducing energy consumption for clients as well as environmental pollution. We provides you with reliable oil purifiers such as transformer oil purifier, turbine oil purification machine, hydraulic oil purifier, lubricating oil filtration machine, fuel oil restoration, oil and water separator, oil regeneration equipment, waste oil recycling equipment etc.
TOP Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.
Honest Team - TOP always honestly treat you and keep faith to make you satisfied with every cooperation with us.
Sincere Communication - TOP sincerely communicate with you to guarantee the provided products to be your ideal ones.
Reliable Quality -TOP own high quality and high performance for every TOP product is under strict quality control and testing.
Service Commitment - TOP bring you prompt, considerate and professional aftersale service and technical support, and explore technology future together.
TOP Oil Purifiers are widespread in the fields of electric power, petrifaction, mineral, shipbuilding, steel construction, bridge, automobile and railway, playing a great role in reducing energy consumption for clients as well as environmental pollution. We provides you with reliable oil purifiers such as transformer oil purifier, turbine oil purification machine, hydraulic oil purifier, lubricating oil filtration machine, fuel oil restoration, oil and water separator, oil regeneration equipment, waste oil recycling equipment etc.
TOP Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.
Honest Team - TOP always honestly treat you and keep faith to make you satisfied with every cooperation with us.
Sincere Communication - TOP sincerely communicate with you to guarantee the provided products to be your ideal ones.
Reliable Quality -TOP own high quality and high performance for every TOP product is under strict quality control and testing.
Service Commitment - TOP bring you prompt, considerate and professional aftersale service and technical support, and explore technology future together.
Certifications
FAQ
1. What is the mini order quantity?
MOQ: generally 1 unit/piece/set
2. What payment methods are supported?
Payment method: By T/T, L/C, Alibaba Trade Assurance etc.
Payment terms: Generally, T/T 40% advanced, the balance paid by T/T when the machine is ready; or 100% irrevocable L/C at sight.
3. What are the available delivery methods?
Our port location: Chongqing, Shanghai or other main port of China
Delivering to: Worldwide
Delivering method: by sea, by air, by truck, by express, combined transportation
4. How long is the product date of delivery probably?
Delivery date differs with product type, order quantity, special requirement etc. Usually our big machine delivery date is around 10 ~ 20 days; test equipment or analyzer delivery date is around 5~10 days. Some products have stock, contact us anytime to get more information.
5. How long is the warranty period?
We warrants the plant supplied under agreed specification against defects in material and workmanship under normal use and service for a period of 2 years after start up of the system.
6. How is the technical services on the product?
Engineer available to service machinery overseas. If you have any technical question, you are welcome to contact us any time. We will response promptly and answer to your satisfaction. If required and necessary, we can send our engineer to your place to provide technical support.
MOQ: generally 1 unit/piece/set
2. What payment methods are supported?
Payment method: By T/T, L/C, Alibaba Trade Assurance etc.
Payment terms: Generally, T/T 40% advanced, the balance paid by T/T when the machine is ready; or 100% irrevocable L/C at sight.
3. What are the available delivery methods?
Our port location: Chongqing, Shanghai or other main port of China
Delivering to: Worldwide
Delivering method: by sea, by air, by truck, by express, combined transportation
4. How long is the product date of delivery probably?
Delivery date differs with product type, order quantity, special requirement etc. Usually our big machine delivery date is around 10 ~ 20 days; test equipment or analyzer delivery date is around 5~10 days. Some products have stock, contact us anytime to get more information.
5. How long is the warranty period?
We warrants the plant supplied under agreed specification against defects in material and workmanship under normal use and service for a period of 2 years after start up of the system.
6. How is the technical services on the product?
Engineer available to service machinery overseas. If you have any technical question, you are welcome to contact us any time. We will response promptly and answer to your satisfaction. If required and necessary, we can send our engineer to your place to provide technical support.
