TYD-20 China Supplier In Stock Hydraulic Oil and Water Separation Plant
- T/T Credit Card
You May Like
-
TYD-10 China Supplier Stainless Steel Cutting Oil and Water Separation Plant
-
China Supplier TYS-S-1 Stainless Steel Waste Cooking Frying Oil Decoloration Machine
-
PL-200 In Stock Hot Sales Used Diesel Oil Plate Press Filtering Equipment
-
TYR-150 On Promotion Vacuum Type Used Black Diesel Oil Filtering and Decoloring Machine
-
2021 TYR-100 In Stock Red Used Diesel Oil Filtering and Purifying Equipment
-
Coconut Milk Dehydration Machine Vacuum Fruit Oil Filtration System
Product Description
Item | Unit | TYD-30 | TYD-50 | TYD-100 | TYD--150 | TYD-200 | TYD-250 | TYD-300 | ||||||||
Flow rate | L/h | 1800 | 3000 | 6000 | 9000 | 12000 | 15000 | 18000 | ||||||||
Working vacuum | MPa | -0.08~-0.099 | ||||||||||||||
Vacuum pressure | MPa | ≤0.3 | ||||||||||||||
Temperature range | ℃ | 20~80 | ||||||||||||||
Power | 3ph 380V 60Hz(or as need) | |||||||||||||||
Working noise | dB(A) | 75 | 75 | 75 | 75 | 80 | 80 | 80 | ||||||||
Heating power | kW | 30 | 30 | 45 | 60 | 75 | 90 | 120 | ||||||||
Total power | kW | 35.5 | 37.5 | 52.5 | 71.4 | 86.5 | 102.5 | 135 | ||||||||
Oil Inlet/Outlet | mm | φ25 | φ32 | φ42 | φ50 | φ50 | φ60 | φ60 | ||||||||
Weight | Kg | 600 | 800 | 1050 | 1400 | 1800 | 2000 | 2200 | ||||||||
Overall | Length | mm | 1050 | 1100 | 1200 | 1450 | 1600 | 1800 | 1900 | |||||||
Width | mm | 750 | 800 | 950 | 950 | 1100 | 1200 | 1200 | ||||||||
Height | mm | 1350 | 1400 | 1500 | 1650 | 1800 | 1900 | 1900 | ||||||||
Breakdown Voltage | kV | ≥75 | ||||||||||||||
Moisture content | PPM | ≤3 | ||||||||||||||
Gas content | % | ≤0.1 | ||||||||||||||
Impurity size | micron | ≤1 (no free carbon) | ||||||||||||||
IFT | dynes/cm | ≥40 | ||||||||||||||
Acid value | mg KOH/g | ≤ 0.03 | ||||||||||||||
Dielectric loss factors | tgδ(90℃) | ≤0.001 | ||||||||||||||
This machine is used for the regeneration treatment of high precision lubricating oils such as used hydraulic oil, refrigerator oil, antiwear hydraulic oil etc. TYD series is designed for purifying oils with high water content.
1.ZY series vacuum transformer oil purifier
2.ZYA series vacuum automatic transformer oil purifier
3.ZYB series vacuum transformer oil regeneration purifier
4.ZYD series double-stage vacuum transformer oil purifier
5.ZYD-I series ouble-stage transformer oil regeneration purifier
6.ZYD-M series trailer-mounted transformer oil purifier
7.TY series vacuum turbine oil purifier
8.TYA series vacuum lubricating oil purifier
9.TYB series coalescence-separation oil purifier
10.TYC series vacuum lubricating oil regeneration purifier
11.CYA series centrifugal oil purifier
12.TPR series waste engine oil recycling system
13.PL series plate and frame oil filter press
14.JL series portable oil purifier
15.BZ series transformer oil regeneration device
MOQ | 1 Set |
Trade Terms | EXW, FOB, CIF, CFR |
Payment Terms | T/T, L/C |
Port of Loading | Any Port of China |
Packing Method | Internaional Standard Wooden Case |
Transportation Method | By Sea, By Land, By Air, By Express |
Supply Capability | 100 Sets/Month |
* The warranty period is 24 months from commissioning acceptance date on. After the warranty period is over we provide lifelong maintenance and technical service.
* We guarantee the maintenance time no more than 3 working days and response time within 1 hour.
* We build instrument service profile for our clients to record the product service and maintenance conditions.
* After instruments start service, we will pay follow-ups to collect the service conditions.
