Home > Products > veneer dryer machine > Woodworking Plywood Core Veneer Roller Conveyor Dryer Machine
Woodworking Plywood Core Veneer Roller Conveyor Dryer Machine
- Qingdao
 - T/T L/C D/P D/A Other
 - 30 days

You May Like
-


Woodworking Plywood Core Veneer Roller Conveyor Dryer Machine
 -


Automatic Plywood Veneer Vertical Horizontal Together Composer Machine
 -


Automatic Adjustable Plywood Core Veneer Composer Jointer Machine
 -


Automatic Adjustable Plywood Core Veneer Composer Jointing Machine
 -


Automatic Adjustable Plywood Core Veneer Composer Jointing Machine
 -


Short Cycle Melamine Laminating Hot Press for HDF Laminate Flooring, Furniture

Product Details
| Brand Name | METRO MACH LEAD TOP | Place of Origin | China | |
| Model Number | BG1333-2 | Certification | CE,ISO,FDA,SGS CCC | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 Year | |
| Weight | 68000Kgs | Dimension(L*W*H) | 23000*5200*4010mm | |
| Condition | New | Voltage | 380/415V | |
| Power(W) | 117.5KW | Type | Other, Veneer dryer machine |
Product Description
Main features:
This series of roller dryer is one of the main machines in plywood production line. It is very suitable for wet clipping processing and drying thick veneer.
Advantage:
New technology and advanced PLC controlling system have been used for effective and quality drying veneers with lower energy consumption.
The BG1333 roller dryer machine is 13 sections as a standard, 2 meters as a standard for one heating section, one cooling section, one conveying system, one input roller table, and one output roller table. Customers can use the machine from 8 sections to 18 sections that it is up to your needs.
Technical specifications:
| Machine model | BG1333-I |
| Density | 550Kg/m3 |
| Veneer thickness range | 1.5-3.6mm |
| Initial moisture content | 80% |
| Final moisture content | 10% |
| Load ratio | 80% to 85% |
| Woking width | 2800mm |
| Working decks | 3decks |
| Length of heating section | 2000mm x 8 sections |
| Length of cooling section | 2000mm x 1 section |
| Transmission speed | 0-15m per min |
| Drying capacity | 3-4m3 per hour |
| Steam consumption | 2100kg per hour |
| Installation motor power | 117.5kw |
| Transmission motor power | 7.5Kw x 3sets |
| Ventilation motor power | 11Kw x 8sets |
| Cooling motor power | 7kw |
| Machine oveall dimension | 23000x5200x4010mm |
| Machine net weight | 68000Kgs |
